Technical Information
8.3
MRcard PL
The MRcard PL is a plug-in card for extending the basic variants by an LTE cellular
modem with two digital inputs and integrated power supply. The MRcard PL is al-
ready contained in the basic variant MRX LTE. The technical data of the basic vari-
ant MRX LAN are extended by the following data with inserted MRcard PL.
8.3.1 Technical Data
8.3.1.1 Physical Features
All specified data was measured with nominal input voltage, at full load, and an
ambient temperature of 25
variations.
Physical Feature
Max. transmission power cellular
engine
EGSM 900
GSM 1800
UMTS 900/1800/2100
LTE 800/900/1800/2100/2600
Weight
Dimensions (Width x Height x Depth
(w/o protruding connectors))
Max. temperature range
Table 11: MRcard PL – physical features
The specifications for the power supply and the inputs can be found in
the basic variant section.
The maximum temperature range of the router may be limited by
narrower temperature ranges of the inserted MRcards (see Table 2).
34
. The limit value tolerances are subject to the usual
℃
Value
+33 dBm
+30 dBm
+23 dBm
+23 dBm
85 g
27 x 117 x 81 mm
-30 ... 75 °C extended
-30 ... 70 °C standard
MRX
