RANGE FOR CONTROL PARAMETER
Parameter Range for J, K, PT100
PB
0.0 to 999.9°C
IT 0 to 9999
DT 0 to 9999
CT 4 to 99 sec
Pb2 2 to 20°C
Ct2 4 to 99 sec
MR -9 to 9°C
OFFSET -20 to 20°C
HYS1 1 to 100°C
HYS2 1 to 100°C
C-PB 2.0 to 25.0°C
C-ON 1 to 20 sec
C-OFF 5 to 200 sec
R1DL
0.0 to 99.59 (mm.ss) 0.0 to 99.59 (mm.ss)
0.0 to 99.59 (mm.ss) 0.0 to 99.59 (mm.ss)
R2DL
ALTM 0 to 99 sec

ERROR DISPLAY

When an error has occurred the display indicates error codes
as given below.
ERROR
OPEN
SRE
CORRECTIVE ACTION:
Check the sensor and the input wiring. If problem still
exists,replace the sensor. And still if problem is not
solved yet by the user, then please contact company
person
Range for PT.1 sensor
0.0 to 999.9°C
0 to 9999
0 to 9999
4 to 99 sec
2 .0 to 20.0°C
4 to 99 sec
-9.0 to 9.0°C
-20.0 to +20.0°C
0.1 to 100.0°C
0.1 to 100.0°C
2.0 to 25.0°C
1 to 20 sec
5 to 200 sec
0 to 99 sec
MEANING
Sensor is not connected or
Over range condition or
sensor break
Sensor connection is
reversed
SOAK TIME FUNCTION
Soak feature can be use to hold the process at a preset
temperature for a preset time.
(Range : selectable up to 0 to 999 hour)
When soak time is completed, then display indicate
message as shown below.
2 345
END
Soak time memory (MEMO)
MEMO
YES /NO
YES : In case of power supply failure, remaining soak time
counting will be continued at next power on.
NO : In case of power supply failure, soak time counting will
be restarted at next power on.
Soak time end (END)
END
SAVE /NO
In case of soak time end, if user apply SAVE in
configuration then soak time end (END) display will still
indicate after power supply failure. And that will only reset
by pressing key for 3 sec.
To restart process
press key for 3 sec.
