- Page 1 Maxprobe User Manual Version 2.0 Focusing on the Future Scanprobe Techniques Limited d mmm yyyy...
-
Page 2: Table Of Contents
Safety Instructions ......................7 Battery Safety Precautions ........................8 General Safety Precautions ........................ 9 Intended Use ........................11 About Your Maxprobe System ......................11 Operating Temperatures ........................12 Prior to Use ........................13 Maxprobe System Overview ..................... 14 Design and Application ........................14 Maxprobe Camera Control Unit ...................... -
Page 3: Maxprobe User Manual
User Notes ......................... 49 Figures Figure 1: Full Maxprobe System ..................14 Figure 2: Maxprobe Camera Control Unit Outer Case ............15 Figure 3: Maxprobe Camera Control Unit Opened .............. 15 Figure 4: CCU Front Connectors ..................16 Figure 5: Maxprobe Camera Control Unit Rear ..............16 Figure 6: Maxprobe Keyboard Layout ................. - Page 4 Scanprobe Techniques Limited Ltd and then only on the condition that this confidentiality clause in unmodified form is included in any such reproduction.
-
Page 5: Introduction
• The Maxprobe Lite system fitted with 40m pushrod. The Maxprobe range is not suitable for use in mines susceptible to firedamp, nor in hazardous areas with explosive dust or gas atmospheres, due to the explosive hazards associated with these locations. If there is a potential to encounter explosive conditions during the planned survey or inspection, equipment designed for ATEX operations should be used. - Page 6 Basic user instructions and maintenance tasks are covered within this User Manual. Basic operation and functionality of the Maxprobe System while surveying or inspecting pipelines is also included in this document, to provide instruction on the correct way to set-up, operate, and maintain all aspects of the Maxprobe System.
-
Page 7: Safety Instructions
Warning: Risk of Injury The fully kitted Maxprobe systems range from 32kg to 58kg. Observe safe lifting procedures when lifting or moving any components of this system and use two- person lifts where appropriate. -
Page 8: Battery Safety Precautions
Maxprobe System when it is connected to an external power source. Battery Safety Precautions The battery is positioned securely within the Maxprobe CCU case. This provides the battery with significant protection from adverse conditions, so the battery will not pose a hazard to operators or co-workers during normal use. -
Page 9: General Safety Precautions
General Safety Precautions Always stay vigilant while operating the Maxprobe System and remain aware of your surroundings. Use the correct personal protective equipment, tools, warning signs and barriers to ensure your own safety, and that of other people nearby. - Page 10 Maxprobe User Manual To reduce the risk of injury or damage to the Maxprobe System, all operators and maintenance personnel must read and understand the user manual before operating the system, changing accessories, or performing maintenance on this camera equipment.
-
Page 11: Intended Use
Maxprobe User Manual Intended Use The Maxprobe System is designed as a CCTV pipeline survey and inspection system and is suitable for use in non-hazardous locations to survey 50mm to 300mm (2” to 12”) pipelines and sewers up to 120 metres in length using a full-colour video camera fitted to the end of a pushrod. -
Page 12: Operating Temperatures
Charging Temperature: +10°C to +45°C Caution: Do not attempt to operate or charge the Maxprobe CCU outside the recommended temperature specifications, as this may damage the battery. Exposing the battery to temperatures below -20°C or above 60°C may damage the battery or activate the battery’s safety systems, causing a permanent battery failure. -
Page 13: Prior To Use
Maxprobe User Manual Prior to Use Before using the Maxprobe System, the operator is responsible for ensuring that the system is safe and suitable for use, and that the work is effectively planned and being undertaken in an appropriate manner: •... -
Page 14: Maxprobe System Overview
Maxprobe User Manual Maxprobe System Overview Design and Application The Maxprobe Pushrod system consists of the following components: Maxprobe Camera Control Unit (CCU) Maxprobe Coiler Pushrod 44mm Camera head Figure 1: Full Maxprobe System Version 2.0 22 November 2023... -
Page 15: Maxprobe Camera Control Unit
When opened, the lid hinges open to 90°, allowing access to the workstation keypad. This is a showerproof elastomer keypad, connected to the main body of the Maxprobe CCU by a coiled wire (see Figure 3). When opened, the Maxprobe CCU is showerproof (rated to IP54), but in persistent heavy rain it is advisable to set up in shelter to minimise the risk of water ingress. -
Page 16: Figure 4: Ccu Front Connectors
Figure 4: CCU Front Connectors The serial number and product details of the Maxprobe CCU can be found on the reverse of the control box enclosure (see Figure 5). The connectors are found below the product label. -
Page 17: Maxprobe Keypad Layout
Maxprobe User Manual Maxprobe Keypad layout Figure 6: Maxprobe Keyboard Layout Power ON/OFF Settings Sonde ON/OFF mina (CANbus Functionality Only) Wincan Wi-Fi Shortcut Free Text Lights Off Text Font Lights Down Text Size Lights Up Meterage Placement Snapshot File Manager Meterage Counter Reset Version 2.0... -
Page 18: Maxprobe Ccu Connectors
Maxprobe User Manual Maxprobe CCU Connectors The Maxprobe CCU has been designed to connect to all Scanprobe Techniques Limited pipeline inspection systems. On the rear of the CCU there will be three or four connectors, depending on whether the CCU is CANbus compliant (ATEX) or not (see Figure 7). If the CCU is CANbus compliant, connector 1 will be present, otherwise this will be absent. -
Page 19: Figure 8: 7-Pin And Power Socket
Maxprobe User Manual 7 Pin Socket and Power Socket Engagement Figure 8: 7-Pin and Power Socket Align the keyway clip at 12 o’clock with the socket, as illustrated in Figure 8, then push the connector into the socket until you hear the click of it locating. To disengage, press down on the rubber button on the top of the plug and pull. -
Page 20: Mounting The Ccu
“Meterage Placement” button on the keypad. This can be reset by pressing the “Meterage Counter Reset” button on the keyboard for three seconds. Figure 11: Maxprobe CCU Display Version 2.0 22 November 2023... - Page 21 The black bar down the right-hand side of the screen is used to display a range of icons to indicate the status of the system (see Table 1). The current date and time is shown towards the top of this icon bar below the Survey Mode icon. Table 1: Maxprobe CCU Icons Icon Meaning...
-
Page 22: Battery Charge Icon
Figure 12: CCU Battery Status Icons Battery Life The Maxprobe CCU battery will provide around 8 hours of continuous use, though this will vary depending on the conditions of use and the environment. Constant and high power drain usage (such as using the sonde with the LEDs set to full illumination) will result in a shorter operational life before the CCU needs to be connected to an external power source. -
Page 23: Battery Operating And Charging Temperatures
Charging Temperature: +10°C to +45°C Battery Damage The battery is protected within the Maxprobe CCU case and is not exposed to the user in normal operations. If the case is damaged and the battery pack is exposed: • Return the Maxprobe CCU to Scanprobe Techniques Limited, or an approved service centre, for repairs. -
Page 24: Maxprobe Settings
The settings menu (see Figure 13) is accessed by pressing the “Settings” button on the keyboard and allows users to administer features of the Maxprobe system. Within this menu, users can perform administrative tasks such as adjusting the system time and date, connecting to wireless networks, and connecting to WinCan web. -
Page 25: Maxprobe Pushrod Coilers
Maxprobe Pushrod Coilers Maxprobe systems are available with several different frames, designed to carry different diameter pushrods at different lengths. Although the coilers slightly differ from one another, the overall concept is the same, which makes them more user friendly for operators who become familiar with the products. -
Page 26: Coiler Brake Operation
The Maxprobe pushrod coiler has a mounting plate used to hold the Maxprobe CCU in position, the base of the frame is designed to sit stably on a variety of surfaces and the wheels offer good stability over commonly encountered terrain. -
Page 27: Pushrod Instructions
This will reduce the risk of damage and an imprecise meterage reading. Locator Sonde A sonde locator for the correct frequency will need to be purchased separately to use this function. Contact Scanprobe Techniques for further details on all locator products or visit the website www.scanprobe.com. CANbus Sonde On CANbus Maxprobe systems, the sonde is activated and disactivated using the “Sonde On/Off”... -
Page 28: Maxprobe 44Mm Camera
Figure 18: 44mm Camera Sonde Collar Maxprobe 44mm Camera The Maxprobe 44mm Camera is a sealed, self-levelling camera with integrated LED illumination and may include a magnetic sonde emitting an oscillating magnetic field with a frequency choice of 512Hz (Model No. 1015-1001-0) or 33kHz (Model No. 1015-1002-0). -
Page 29: Connecting Camera To Pushrod
Maxprobe User Manual Warning: Do not attempt to open the camera head at any time. The camera head is not user serviceable and should only be opened by a Scanprobe engineer or agents explicitly authorised by Scanprobe Techniques Ltd. Warning: Do not look directly at the LEDs when illuminated to full brightness. -
Page 30: Removing Camera From Pushrod
Maxprobe User Manual Removing Camera from Pushrod • Using the camera spanners (see Figure 22), loosen the outer shell from the pushrod connector. Figure 22: Use of Camera Spanners • Unscrew the outer shell by hand, taking care not to rotate the camera head or the pushrod connector. -
Page 31: Camera Trolley
Camera Trolley The Maxprobe Camera Trolley is designed for use in pipelines of 150mm to 300mm diameter. The trolley centres the camera head in the larger diameter pipes, lifts the camera head out of any liquid that may be standing or flowing in the pipeline, and also reduces the friction between the camera head and the pipe, providing a smoother survey for less effort. -
Page 32: Figure 24: Fitting Camera To Trolley
Maxprobe User Manual M3 x 25mm screws and washers provided, fasten the front of the skid case to the trolley base. Figure 24: Fitting Camera to Trolley Reconnect the camera head to the pushrod, being careful not to overtighten the connector. -
Page 33: Figure 25: Trolley Fitted With Small Wheels
Maxprobe User Manual For 150mm diameter pipes, use the small wheels and short axles, and remove the ballast weight (see Figure 25. Figure 25: Trolley Fitted with Small Wheels For 225mm and 300mm diameter pipes, use the large wheels and long axles, and attach the ballast weight if necessary. -
Page 34: User Interface
Maxprobe User Manual User Interface Regardless of the survey mode that the Maxprobe system is used in, the main principles of operation remain consistent. This section provides guidance on the basic functionality of the Maxprobe CCU, such as recording video, taking snapshots and annotating recordings. -
Page 35: Writing Text
The Maxprobe CCU will automatically record audio if you plug a microphone into the microphone socket in the CCU front. To hear the audio on a recording during playback through the Maxprobe CCU, you will need to plug in a speaker or a set of headphones into the headphones socket. -
Page 36: Light Adjustment
32Gb onboard SSD by default. This should be regularly cleared up by copying all reports onto a USB drive or to a computer then deleting the file from the Maxprobe CCU. Using more that 75% of the onboard SSD for storing old reports and video can lead to the Maxprobe CCU becoming unresponsive or freezing up. -
Page 37: Deleting Files
Maxprobe User Manual copied file. Select the desired destination then press the “OK” key. A graphic showing the file transfer in progress will be displayed on the CCU screen. Depending on the size of the files being transferred and the read/write speeds of the device being copied to, this can take some time to complete. -
Page 38: After Use, Care And Maintenance
• Check O-rings for damage and replace if necessary (grease regularly). • If damage is identified, contact Scanprobe Techniques or its authorised agents. Cleaning and Maintenance Caution: Risk of Damage Check to make sure there are no external devices remaining plugged into the front connectors, and that there are no objects on the keyboard, before closing the keyboard. - Page 39 The individual system components should be kept clean and in good condition to increase the longevity of your Maxprobe CCU and to reduce the risk to the operator while operating the system. Maintaining the system in a clean working condition will also reduce abrasion Version 2.0...
-
Page 40: Repairs
After use, the Maxprobe CCU should be recharged by connecting the charging leads to a suitable external 12V or mains power source. -
Page 41: Maxprobe System Interchangeability
The CCU is designed to control all Maxprobe systems, as well as the TrapJumper, as shown in Figure 27. Note that a CANbus CCU is required to operate the CANbus systems. These cannot be controlled using a non-CANbus CCU. -
Page 42: Maxprobe Accessories
Check the accessories before using this product. Warning: Keep the accessories out of reach of children to prevent swallowing. This sets out the standard accessory kit provided with the Maxprobe system. The Maxprobe 120 may also include the Camera trolley and roller skids. Version 2.0... -
Page 43: Charging Accessories
Maxprobe User Manual Scanprobe Techniques continue to offer a wider range of protective sleeves and equipment for the Maxprobe 44mm cameras, please check the website site for new accessories www.scanprobe.com. Charging Accessories The Maxprobe CCU charging leads: Part Number Image... -
Page 44: Troubleshooting
Press the power button. powered CCU shuts off Battery is depleted Charge the battery. No camera Fit a Maxprobe 44mm Camera Dirt in the camera Clean the camera connector and refit the connector camera. Check the cable between the coiler and CCU... - Page 45 Incorrect cable incomplete. Use the approved Maxprobe to CCU Cable. configuration. During data No Wi-Fi signal Move closer to an access point. communication over Wi-Fi, no data You moved out of...
-
Page 46: Disposal
The Maxprobe System, and the component parts, are classified as electrical equipment and is covered by the Waste Electrical and Electronic Equipment Regulations 2013 (as amended). The Maxprobe CCU contains batteries and by law must not be disposed of in landfill waste. -
Page 47: Technical Data
Maxprobe User Manual Technical Data Coiler Data Description Maxprobe Maxprobe XL Maxprobe 120 Cable Length 60 m 100 m 120 m Meterage counter Driving Force Manual (push rod) Manual (push rod) Manual (push rod) 12v DC / 230v AC /... -
Page 48: Camera Data
Maxprobe User Manual Description Maxprobe CCU Data Export USB 2.1 x 2, Wi-Fi, 4G Wincan Embedded + Wincan Web Software Basic Survey Mina Survey Output 800 x 600 SVGA, DE15 Video format MPEG4 Image format JPEG Storage temp. 0°C to 40°C... -
Page 49: User Notes
Maxprobe User Manual User Notes Version 2.0 22 November 2023... - Page 50 Maxprobe User Manual Scanprobe Techniques Ltd Unit 11, Kenley Trade Park, Old Barn Lane, Kenley, Surrey, CR8 5AU www.scanprobe.com sales@scanprobe.com +44 (0)20 3253 2001 Version 2.0 22 November 2023...
