Summary of Contents for Scanprobe X40
- Page 1 X40 User Manual Focusing on the Future Scanprobe Techniques Limited...
-
Page 2: Table Of Contents
Figure 3: X40 System Components ........................ 10 Figure 4: TrapJumper Camera .......................... 11 Figure 5: X40 Coiler Product Label and Serial Number ................11 Figure 6: TrapJumper Camera Serial Number .................... 12 Figure 7: CCU and Charger Connector ......................16 Figure 8: Connecting the TrapJumper Camera .................. - Page 3 Scanprobe Techniques Limited Ltd and then only on the condition that this confidentiality clause in unmodified form is included in any such reproduction.
-
Page 4: Introduction
Scanprobe Techniques) or with compatible mobile devices using the X-range or mina applications. The X40 System is not designed for use in mines susceptible to firedamp, nor in hazardous areas where explosive atmospheres may be present. -
Page 5: Safety Instructions
Battery Care The battery is protected within the X40 System case and is not exposed to the user in normal operations. If the case is damaged and the battery pack is exposed: Call Scanprobe Techniques Limited, or an approved service centre, to arrange for ... -
Page 6: General Safety Precautions
Use the correct personal protective equipment, tools, warning signs and barriers to ensure your own safety, and that of other people nearby. To reduce the risk of injury or damage to the X40 System, all operators and maintenance personnel must read and understand the user manual before operating the system, changing accessories, or performing maintenance on this camera equipment. -
Page 7: Intended Use
About Your X40 System The X40 System has been designed as a CCTV pipeline survey and inspection system and is suitable for use in non-hazardous locations. It consists of 40 meters of flexible pushrod with a robust outer jacket and a camera head designed to negotiate several tight bends within pipe sizes varying from 50mm up to 150mm. -
Page 8: Disposal
Disposal The X40 System is classed as electrical equipment and is covered by the Waste Electrical and Electronic Equipment Regulations 2013 (as amended). The X40 coiler and the Maxprobe™ CCU both contain batteries and by law must not be disposed of in landfill waste. -
Page 9: X40 Overview
X40 Coiler The X40 Coiler contains the electronics hub and gathers the push rod in a uniformed and redistributable way. The X40 Coiler has been designed to be compact and user friendly. The top of the frame has a device holder used to hold a tablet or smart device in position and the base of the frame is designed to sit stable on a variety of surfaces (see Figure 2). -
Page 10: Trapjumper Camera
Battery Breather Device Holder Camera Clip Figure 3: X40 System Components TrapJumper Camera The TrapJumper Camera is illustrated in Figure 4. It is a sealed unit, rated to a depth of 3 metres in standing water. The camera provides a self-levelling picture with integrated LED illumination and a magnetic sonde emitting an oscillating magnetic field with a choice of two frequencies, 512Hz or 33kHz. -
Page 11: Component Identification
Warning: Risk of damage to eyes and eyesight: The X40 System features bright LED illumination on the camera head which may cause damage to the eyes or to eyesight when fully illuminated. Do not look directly at them or point them at other people’s eyes when illuminated. -
Page 12: Trapjumper Camera Head
Be aware of your surroundings and any sources of danger that may cause serious harm or even fatal injuries. Before using the X40 System, the following checks should be undertaken: The operator must ensure that all connectors and other interfaces are kept free ... - Page 13 When using the Maxprobe™ CCU, if any water has penetrated the box, do not connect the CCU to the mains and inform Scanprobe immediately. Electrical work on the X40 System must only be carried out by Scanprobe Techniques Ltd or Scanprobe trained specialist engineers.
-
Page 14: Planning And Organisation
Follow all safety instructions as described in this document. As the operator of the X40 Camera System, it is your responsibility to ensure the following: Use the camera system exclusively for the works described in the Intended Use ... -
Page 15: X40 Use
X40 Use Power Button To power up your X40 coiler, please ensure there is significant charge in the battery within the unit. Please refer to the X-Range charging procedure for further details. The ON/OFF button located on the side of the X40 has uses the following functionality:... -
Page 16: Figure 7: Ccu And Charger Connector
SX40 User Manual Figure 7: CCU and Charger Connector Warning: Do not force the connector as this will result in damage. If you’re struggling to get the connectors to mate, check the keyway is aligned and there is no dirt obstructing connectivity. -
Page 17: Charging Procedure
The X40 lithium-ion battery pack contains lithium ion cells and are subject to shipping regulations. Certification for the requirements of UN38.3 can be provided by Scanprobe Techniques Ltd. The X40 battery pack is less than the 100Wh shipping limit permissible for each battery. -
Page 18: Battery Maintenance
For maximum battery life, recharge the battery when it reaches 50% charge, and charge to between 80-90% of the maximum capacity. Do not leave the X40 system plugged into the charger once the battery is fully charged, as this will also degrade the battery life. -
Page 19: Connectivity
X40 User Manual Connectivity The X40 System has been designed with connectivity in mind. The X40 System is designed to be controlled by smart phones, iPads, tablets and the Maxprobe CCU. Figure 9: X-Range Connectivity Maxprobe CCU The Maxprobe CCU is a bespoke control unit specifically designed for the use in the pipeline inspection sector. - Page 20 SX40 User Manual X-Range App The X-Range application is a bespoke software platform designed to incorporate all the functionality of the Maxprobe™ CCU on a tablet and offers all the benefits that come with tablet designs i.e., touch screen, multiple sharing options, light-weight design. etc. The X-Range application offers three options: 1.
- Page 21 X40 User Manual Application Support There is online help available within the “mina” and X-Range applications, using the “help” icon found within the software, or on the Maxprobe™ CCU by hitting the “Help” button on the keyboard. Alternatively, you can speak to one of our team by contacting the service department at Scanprobe.
-
Page 22: Accessories
If required, the X-Range to Maxprobe Cable (Part No. 1007-2061- 0) is also available for separate purchase; this item is not provided as standard with an X40 System, unless the X40 System is purchased with a Maxprobe™ CCU. -
Page 23: After Use, Care And Maintenance
The individual system components should be kept clean and in good condition to increase the longevity of your X40 System and to reduce the risk to the operator while operating the system. Maintaining the system in a clean working condition will also reduce abrasion and other wear and tear on the components while in use to significantly extend the operational life of the system and it will help to minimise repairs. -
Page 24: Repairs
Opening these enclosures may be dangerous and is liable to damage or destroy the seals protecting this equipment. Due to the specialist knowledge and tools required to repair and reseal the X40 System components and verify that these repairs have been completed correctly, all repair work... -
Page 25: User Notes
X40 User Manual User Notes Version 1.0 29 June 2022... - Page 26 SX40 User Manual Version 1.0 29 June 2022...
- Page 27 Scanprobe Techniques Ltd Unit 11, Kenley Trade Park, Old Barn Lane, Kenley, Surrey, CR8 5AU www.scanprobe.com sales@scanprobe.com +44 (0)20 3253 2001...
