Chapter 3: Specifications

3-1. Specifications

Display function
Power supply
Operating temperature
Storage temperature
Altitude
Indoor use only
Installation category
Pollution degree
Ambient humidity
External dimensions
Weight
Electrostatic discharge

3-2. Connector pin number and signal

Pin number
1
2
3
4
5
6
7
LCD 16 digit × 4 lines
Supplied from the controller via connection cable
5～40℃
-20～60℃
up to 2000m
Ⅱ
2
20～80%RH (no condensation)
120W×160D×53H [mm](excluding projections)
About 0.7 [kg]
EN61000-4-2(2009) Level 2
Table3-2 Connector pin assignment
Signal name Pin number
SG
+5V
TXD+
RXD+
STOP
-
-
-12-
SC29302-K13-18002B
Signal name
8 SG
9 +5V
10 TXD-
11 RXD-
12 CONNECT-
13 -
14 -
