2-3. Checking and Setting Memory Switches

This product able to change memory switch of SHOT-302GS/SHOT-304GS/SHOT-702H
controller of the memory switch controller.
NOTE) This function is only usable with SHOT-302GS/SHOT-304GS and SHOT-702H.
(*) For more information about memory switch, refer to User's manual of SHOT-
302GS/SHOT-304GS and SHOT-702H.
NOTE) IN SHOT-702/PGC-04-U/HSC-103/SHRC-203, the Memory switch mode is invalid.
Changing Memory switch settings
T o display the memory switch setting screen when using the SHOT-302GS/SHOT-304GS, set to manual mode (M).
Press the【 MODE 】 and【 E-ORG 】 buttons simultaneously press, Memory switch settings can be changed.
Button
Joystick UP side
Joystick down side
Joystick right side
Joystick left side
【MODE】and【ZERO】 ①Cycle through options for the current item (or increase the
【SPEED】
【MODE】
【MODE】and【ZERO】
OR
【SPEED】
OR
【MODE】
【MODE】 and 【M-ORG】 Restore memory switch settings to factory defaults
T able2-3-1 Checking and Setting Memory Switches
Cycle through items in descending order (No.2⇒1⇒86⇒85)
(*) In case of SHOT-702H (No.45⇒46⇒1⇒2)
Cycle through items in ascending (No.85⇒86⇒1⇒2)order
(*) In case of SHOT-702H (No.2⇒1⇒46⇒45)
For numeric options, move cursor to right digit
For numeric options, move cursor to left digit
value of numeric options)
② After changes to settings have been completed, save
changes to settings and exit
①Cycle through options for the current item (or decrease the
value of numeric options)
② After changes to settings have been completed, cancel
changes to settings and exit
①Press to end changes to settings (a confirmation screen will
be displayed)
②When setting is completed ※１
YES
NO,
CANCEL
