2-2. Operating method

① LCD panel
MODE
H 1 :
AXIS 1
1 2 :
AXIS 2
3 :
AXIS 3
4 :
AXIS 4
SPEED
Display the position coordinates for each axis and the operating mode.
Display Digit : 16 digit × 4 lines
②【MODE】button
Change an operation mode of the controller.
HOST→MANUAL・・・
Refer to a User's Manual of SHOT-302GS/SHOT-304GS/SHRC-203 for various modes.
NOTE) IN SHOT-702/SHOT-702H/PGC-04-U/HSC-103, the MODE change is invalid.
③【E-ORG】button
Position stage at logical origin "0" for all axes.
The button's LED indicator lights up when the stage is moving and lights off
when the stage is at logical position.
④【ZERO】button
Reset position coordinates for all axes to zero.
⑤【Axis select】 button
Selects the axis operated by joystick as " 1 and 2 axis" or "3 and 4 axis".
The LED indicator lights up when "3 and 4 axis" can be operated by joystick.
NOTE) This button is usable with SHOT-304GS/PGC-04-U/HSC-103/SHRC-203.
A sign±
+ 1
+ 2
+ 3
+ 4
Fig.2-2-1 Display content example
※When you disconnected stage,displayed "+ -".
