1-2. Connecting method
This product is connected to the controller with MDR14-CA cable.
① Connect a standard cable (MDR14-CA-*) to the connector on the rear panel of the JS-301.
② Connect the cable from the JS-301 to the "JOYSTICK" or "OPTION" of the connector on
the front panel of the SHOT-30X series, PGC-04-U and SHRC-203 controller.
(In the case of SHOT-702/SHOT-702H/HSC-103, it becomes the rear panel part.)
③ Turn power switch of the controller on.
And confirm that the open message is displayed correctly. If it can not be displayed,
reconfirm if connection of cable is done correctly.
Be sure the controller is off when you connect this product. You may not
able to use the buttons and so on this product if you connect or disconnect
either device while the controller is on.
SC29302-K13-18002B
-7-
