⑥Joystick
Enables operation of "1 and 2 axis" or "3 and 4 axis".
A move of the joystick continuously moves the stage continuously.
Releasing the stick stops the stage.
Move the joystick again after putting the joystick in neutral for over a second when
inverting moving direction of each axis. It may not work without the required
operation.
⑦【M-ORG】button
Moves the stage to its mechanical origin.
The button's LED indicator lights up when the stage is moving and lights off when the stage is
at mechanical origin position.
⑧Third axis operation switch
Use the switch to operate third axis.
Push the switch to Top : + direction
Push the switch to Bottom : - direction
NOTE) This button is usable with SHOT-304GS/PGC-04-U/HSC-103/SHRC-203.
⑨【SPEED】button and SPEED LED
Cycle through "SPEED 1/2/3/4" settings stored in controller's memory switches
(1→2→3→4→1・・・).
Change the number of lightning of LED indicator by the SPEED button every time pushing the
button. Its number of lightning of LED indicator enables you to check current moving speed.
When "●" position means lightning LED. Number of lightning LED means speed value.
Fig.2-2-2 Number of Shining LED means speed value
⑩【STOP】button
If you were push this button, all operating motorized stages stop.
Refer to the manual of each controller for stopped condition.
SPEED
1
〇
〇
〇
●
Don't use other cable that MDR14-CA cable.
SC29302-K13-18002B
2
3
4
〇
〇
●
〇
●
●
●
●
●
●
●
●
-10-
