112 SETTING

MIRRORS

Adjusting the mirrors
Move mirrors into desired po-
sition by rotating them.
Adjusting the mirror arm
Slide up protective cap 1 for
screw connection on mirror
arm.
Loosen lock nut 2.
Turn the mirror arm into the
desired position.
Tighten lock nut to specified
torque while holding mirror
arm in place.
Mirror with lock nut on
adapter
M10 x 1.25
Mirror with lock nut on
adapter
16 lb/ft (22 Nm) (Left-hand
thread)
Slide protective cap 1 over
threaded connection.

HEADLIGHTS

Headlight range and spring
preload
The headlight range gener-
ally remains constant due to
the adjustment of the spring
preload to the load status. The
headlight beam throw is cor-
rectly adjusted at the factory.
If there are doubts as
to the correct headlight
range, have the setting checked
by a repair shop, preferably by
an authorized BMW Motorrad
dealer.
