Navigation System - BMW S 1000 XR 2023 Rider's Manual

202 ACCESSORIES
Press the carrying handle 1
down until it snaps in.
Turn key in topcase lock to
the 1 position and remove.
Maximum payload and
maximum speed
Observe maximum payload and
maximum speed.
The following values apply to
the combination described
here:
Maximum speed when
riding with a loaded
topcase
max 112 mph (max
180 km/h)
Payload of Topcase
max 22 lbs (max 10 kg)

NAVIGATION SYSTEM

Fastening navigation system
securely
with preparation for naviga-
tion system OE
with navigation system
The navigation prepa-
ration is suitable for
BMW Motorrad Navigator IV
and later.
The locking system of the
Mount Cradle offers no
protection against theft.
Remove the navigation system
and store in a safe place after
every drive.
Turn the ignition key 4 coun-
terclockwise.
Pull the shut-off lock 2 to the
left.
OA
