190 MAINTENANCE
Insert the holder 2 into the
bracket 3 and install it.
Install screws 1.
Connecting battery to vehicle
( 189)
Install the seat. (
Configure system settings.
( 70)

FUSES

Replacing fuses
ATTENTION
Bypassing defective fuses
Risk of short circuit and fire
Do not bypass defective
fuses.
Replace defective fuses with
new fuses.
Turn off the ignition.
Park the motorcycle, making
sure the ground is level and
firm.
Remove the seat. (
Remove screws 1.
107)
electrical system checked by
a repair shop, preferably a
BMW Motorrad dealer.
107)
Carefully detach the side
cover 2 from the holding
clips 3.
Press the lock 1 on both
sides.
Pull off the fuse box 2.
Replace defective fuse in ac-
cordance with fuse assign-
ment.
If the fuses are faulty
frequently, have the
Reinsert the fuse box 2. Make
sure that the lock 1 snaps in
on both sides.
