Kramer Electronics Ltd. Contents Introduction Getting Started Overview Typical Applications Defining EXT3-C-WP-XR-T 4K60 USB-C Wall Plate Transmitter Defining the EXT3-C-WP-XR-T Front and Rear Panels Mounting EXT3-C-WP-XR-T Mounting EXT3-C-WP-XR-T in a Wall Box Connecting EXT3-C-WP-XR-T Defining the DIP-switches Connecting to EXT3-C-WP-XR-T via RS-232...
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we...
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/il/quality/environment.
Page 5
HDMI Support – Support HDR10, deep color, x.v.Color™, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0. • I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID handling, processing, and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
• Corporate – Hybrid and online meetings. • Education – Hybrid and online learning and training. • Any AV, Ethernet and USB room extension applications such as conference rooms, boardrooms, and training facilities. EXT3-C-WP-XR-T – Introduction...
Kramer Electronics Ltd. Defining EXT3-C-WP-XR-T 4K60 USB-C Wall Plate Transmitter Defining the EXT3-C-WP-XR-T Front and Rear Panels Figure 1: EXT3-C-WP-XR-T 4K60 USB-C Wall Plate Transmitter Front Panel Feature Function USB-C IN Connector Connect to a USB-C AV source (that supports DisplayPort Alternate Mode) for AV input, USB host connection to local and remote connected USB devices.
Page 8
Press to toggle power on/off the remote CEC-enabled display that is connected to the receiver side. Button LED lights blue when remote display power is on. Figure 2: EXT3-C-WP-XR-T 4K60 USB-C Wall Plate Transmitter Rear Panel Feature Function Ring Tongue Terminal Connected to grounding wire.
• Avoid uneven mechanical loading. • Appropriate consideration of equipment nameplate ratings should be used for avoiding overloading of the circuits. • Reliable earthing of rack-mounted equipment should be maintained. • Maximum mounting height for the device is 2 meters. EXT3-C-WP-XR-T – Mounting EXT3-C-WP-XR-T...
Kramer Electronics Ltd. Mounting EXT3-C-WP-XR-T in a Wall Box Insert the device into the in-wall box (note that first you need to connect the HDBT cable and power) and connect the parts as shown in the illustration below. When installing the device, take care not to obstruct the upper and lower ventilation holes.
Switch off and disconnect the power to each device befo your devices, connect their power and power-up each d To connect EXT3-C-WP-XR-T to EXT3-POE-XR-R as illustrated in the example in Figure 1. If required, set to active HOST via DIP-switch 2 (see Defining the DIP-switches on page 11).
Page 12
For example, we recommend connecting a keyboard and mouse to the USB 2 port on the EXT3-C-WP-XR-T, as they remain connected when the HOST port is disconnected. 7. To control the Monitor via the OUT IR port, connect the following: ▪...
Setup DIP-switches are located behind the top front panel of the device. To access the DIP-switches, simply remove the top front panel. Figure 5: EXT3-C-WP-XR-T DIP-Switches By default, DIP-Switch 2 is set to ON (up), while all the other DIP-switches are set to OFF (down) by default.
Kramer Electronics Ltd. Connecting to EXT3-C-WP-XR-T via RS-232 You can connect via an RS-232 connection using, for example, a controller. EXT3-C-WP-XR-T features an RS-232 3-pin terminal block connector to extend RS-232 signals via the EXT3-C-WP-XR-T transmitter to the connected receiver.
EXT3-C-WP-XR-T supports CEC functionality and has been tested and verified with a large number of display models. However, Kramer cannot guarantee CEC compatibility with all CEC displays due to command variations and proprietary commands implemented by some manufacturers in some of their displays.
On a 3-pin terminal block for serial link extension 1 Gbps LAN On an RJ-45 female connector Extension Line Reach Up to 90m (295ft), when using Kramer HDBaseT cables Standards Compliance HDBaseT 3.0 Video Max Data Rate 18Gbps bandwidth (6Gbps per graphic...
Page 17
This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
Page 18
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
