Scan for full manual
Step 1: Check what's in the box
EXT3-C-WP-XR-T (EU/UK)
Transmitter
1 Power cord and adapter
1 Multi signal USB-C cable (1m)
Step 2: Get to know your EXT3-C-WP-XR-T
EU/
UK
Version Front
#
Feature
1
USB-C IN Connector
2
LOOP HDMI Connector
3
USB A 2.0 Charging Connector 1
USB A 2.0 Charging Connector 2
4
IN LED
5
OUT LED
6
LOOP LED
7
HOST LED
8
LINK LED
9
STATUS LED
10 DISPLAY ON Button
EXT3-C-WP-XR-T Quick Start
EXT3-C-WP-XR-T (EU/UK) Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/EXT3-C-WP-XR-T
firmware upgrades are available.
4K60 USB C
Function
Connect to a USB-C AV source (that supports DisplayPort Alternate Mode) for AV input,
USB host connection to local and remote connected USB devices. Charges sources (that
support USB Power Delivery 2.0) up to 60W when the device is powered via the power
adapter). While charging, the charging icon (to the right of the connector) becomes visible
and lights orange.
Connect to a local acceptor to view the AV signal coming from the USB-C IN input.
Connect to the USB local peripheral devices (for example, a keyboard & mouse). When
USB Host PC is disconnected, the USB signal and charging power for this port are
inactive.
Connect to the USB local peripheral devices (for example, a USB camera, a soundbar,
microphone and so on). When USB Host PC is disconnected, the USB charging power
for this port continues to be active.
Lights blue when an active AV input signal is detected from the source device that is
connected to the USB-C IN port.
Lights blue when an HDMI output device is detected on the receiver side.
Lights blue when an active signal is transmitted on the HDMI LOOP port.
Lights orange when the USB is set to Host.
Lights green when the HDBT connection is active.
Lights green when PSU powered and orange when PoE powered.
Press to toggle power on/off the remote CEC-enabled display that is connected to the
receiver side. Button LED lights orange when remote display power is on.
EXT3-C-WP-XR-T
(EU/GB) for the first time.
to download the latest user manual and check if
1 Upper front panel
1 Lower front panel
1 Quick start guide
EU/
UK
Version Rear
P/N:
2 9 0 0 - 3 0 1 6 5 2 QS
1 Screw set
Rev:
3
