◦ Surveying rucksack
◦ Telescopic pole
◦ Li-ion battery pack
◦ Stainless Steel Offset Bracket
◦ 5/8" stainless steel nut
◦ Rover wheel
◦ Telescopic handle
◦ Extension cable (SMA)
◦ Telemetry antenna
◦ Telemetry antenna bracket with nut
• Ground plane antenna
• TNC-to-SMA antenna cable
►CAN Hub
• CAN Hub unit
• CAN Hub power cable (2 x RLCAB005-18)
Subject vehicle - Setup
IMPORTANT
Connect the Antenna(s) to the VBOX unit before you connect the power.
VBOX 3i ADAS
1. Connect one end of an antenna cable to the connector on the antenna(s).
2. Place the antenna(s) on the roof of the vehicle.
You can read more about how and where to place the GNSS antennas here.
3. Connect the antenna(s) to the antenna port(s) on VBOX 3i ADAS.
Note: The primary antenna is Antenna A and the secondary antenna is Antenna B.
4. Connect the power cable to the PWR port on VBOX 3i ADAS.
5. Connect the Tablet/Laptop to the USB port on the VBOX 3i ADAS with the USB cable (RLCAB066-2).
