Racelogic VBOX 3i ADAS Installing page 10

What happens if you do not carry out this procedure?
If you cannot carry out this procedure as above, the speed accuracy will be reduced, especially for the first
few minutes, until the Kalman Filter is able to calibrate itself.
Radios
►ADAS Radios
1. Connect the Radio antenna to the Radio unit.
2. Place the antenna on the car roof.
Note: The Radio antenna must be at least 50 cm away from any other radio antenna.
3. Connect one end of an RLCAB005 cable to the port on the Radio unit.
4. Connect the other end of the cable to the SER port on the VBOX 3i ADAS.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_3i_Product_Range/VBOX_3i_ADAS/
User_Guide_VBOX_3i_ADAS/04_Installing_VBOX_3i_ADAS_in_the_Vehicle
10
