SETUP FOR EXTERNAL AIR PLASMA CUTTING

Connect the plasma torch to the plasma torch

connection. Tighten the nut once connected to

ensure a secure connection.

Connect the plug into a 230v Power socket,

then switch the machine ON.

RAZORCUT

WARNING: USE COMPRESSED

AIR ONLY WITH THIS MACHINE

Connect the earth clamp to the positive (+)

dinse connection, twist to lock in place

Select EXTERNAL air supply.

RAZORCUT
