SETUP FOR INTERNAL AIR PLASMA CUTTING
Place and hold the torch vertical at the edge of
9
the plate.
To finish the cutting release the torch switch.
11
The air flow will continue for 30 seconds to
cool the torch head. Do not disconnect air
until this cooling period has been completed.
Failure to do this will result in torch head
damage.
Pull the trigger to energise the arc. When the
10
cutting arc has cut through the edge of the
plate start moving evenly in the direction you
wish to cut.
PLEASE NOTE TORCH ILLUSTRATION MAY DIFFER
DEPENDING ON MODEL
