Hardware Installation and Reference Guide
PSE total power consumption ≤ 800 W
PSE total power consumption ≤ 1600 W
PSE total power consumption > 1600 W
When two RG-PA600I-P-F power modules are used, check the redundancy status according to the following
table.
PSE Total Power Consumption
PSE total power consumption ≤ 470 W
PSE total power consumption ≤ 940 W
PSE total power consumption > 940 W
1.2.3
Heat Dissipation
The RG-S5750-24SFP4XS24DP-UP adopts the left-to-right and front-to-right airflow design to ensure that the
switch works properly in the specified environment. A minimum clearance of 100 mm (3.94 in.) must be
maintained around the device to ensure proper ventilation.
Figure 1-5
Airflow Direction
1.2.4
LEDs
LED
Status LED
Panel
Identific
Status
ation
Off
Blinking
green (3 Hz)
Status
Blinking
green (10
Hz)
1+2 redundancy
2+1 redundancy
No redundancy
Redundancy
1+2 redundancy
2+1 redundancy
No redundancy
Description
The switch is not powered on.
The switch is being initialized. If the LED blinks
continuously, a fault occurs.
The system is being located, and can be remotely
enabled or disabled by an O&M engineer.
7
Product Overview
