ACCESSORIES
Rain accessory
10EARA
Bracket accessory
10EABA
75.0072.02 EAGLE ARTEK 20231023
retrofit interface
Ceiling accessories
10EACA (white)
10EACA-BLK (black)
Retrofit interface
10EARETROFIT
Unidirectional opening sensor for
harness (35.1563)
EAGLE ARTEK
automatic doors
(US version)
3
4
1. main connector
2. antenna
3. LEDs
4. push buttons
5. cover
Replacement covers
35.0303 - black
35.0319 - white
35.0320 - silver
Page 1 of 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BEA EAGLE ARTEK
Summary of Contents for BEA EAGLE ARTEK
- Page 1 (35.1563) 5. cover ACCESSORIES Rain accessory Ceiling accessories Replacement covers 10EARA 10EACA (white) 35.0303 - black 10EACA-BLK (black) 35.0319 - white 35.0320 - silver Bracket accessory Retrofit interface 10EABA 10EARETROFIT 75.0072.02 EAGLE ARTEK 20231023 Page 1 of 12...
- Page 2 Page 2 of 12...
- Page 3 • Cutting edge electronics • In-House production for better quality control and supply chain autonomy Our goal is to provide you with user-friendly solutions. EAGLE ARTEK comes with the following improvements: • Compact design - Allows discreet integration with all types of door control, even the slimmest ones •...
- Page 4 Page 4 of 12...
-
Page 5: Mounting Options
Specifications are subject to change without prior notice. All values measured in specific conditions. MOUNTING OPTIONS HEADER MOUNT HEADER (FASCIA) MOUNT CEILING MOUNT HEADER MOUNT sliding revolving swing / sliding / revolving swing / folding 75.0072.02 EAGLE ARTEK 20231023 Page 5 of 12... -
Page 6: Installation Tips
‰ DO NOT attempt any internal repair of the components. All repairs and/or component replacements must be performed by BEA, Inc. Unauthorized disassembly or repair: 1. May jeopardize personal safety and may expose one to the risk of electrical shock. -
Page 7: Mounting And Wiring
+30° 45° 0° 9’ 6’ -30° 9’ 6’ 6’ 6’ 3’ 3’ 0’ 0’ 3’ 3’ 6’ 9’ 6’ 9’ 9’ 9’ Adjust the lateral antenna angle. Adjust the vertical antenna angle. 75.0072.02 EAGLE ARTEK 20231023 Page 7 of 12... -
Page 8: Via Remote Control
Once you have saved an access code, you must always enter this code to unlock the sensor. If you forget the access code, cut and restore the power supply. Within 1 minute, you can access the sensor without introducing any access code. Page 8 of 12 75.0072.02 EAGLE ARTEK 20231023... - Page 9 7 ft long push (2 sec) long push (2 sec) IMMUNITY EXIT ENTER increase decrease long push (2 sec) long push (2 sec) FACTORY RESET – full reset only long push (4 sec) 75.0072.02 EAGLE ARTEK 20231023 Page 9 of 12...
-
Page 10: Troubleshooting
Remote control not aimed at Point the remote control towards the sensor sensor. Door remains open, Door control is set to “open” Set the door control to “auto” (see pg. 8). LED stays on Page 10 of 12 75.0072.02 EAGLE ARTEK 20231023... - Page 11 BEA, Inc. does not guarantee any use of the sensor/device outside of its intended purpose. BEA, Inc. strongly recommends that installation and service technicians be AAADM-certifi ed for pedestrian doors, IDA-certifi ed for doors/ gates, and factory-trained for the type of door/gate system.
- Page 12 Page 12 of 12...
