  • Page 1 ® - FLATSCAN REV-PZ COMPACT LASER SCANNER FOR THE SAFETY OF REVOLVING DOORS User’s Guide for product version 0100 and higher...

  • Page 2: Led Signals

    DESCRIPTION The LZR -FLATSCAN REV-PZ is a safety sensor for automatic revolving doors based on laser ® technology. It secures the area in front of the leading post of the drum wall (pinch zone). To do so, the sensor must be installed in the canopy of the door. Sensor body Laser window protection Angle adjustment screw...

  • Page 3: Safety Tips

    SAFETY TIPS The device contains 2 visible laser beams that can be activated during the installation process to adjust precisely the position of the detection field. CLASS 1 LASER PRODUCT CLASS 1 LASER PRODUCT CAUTION! CLASS 3R LASER Do not look directly into these red beams or laser emitters (Class 3R). RADIATION ACCESSIBLE DURING INSTALLATION.

  • Page 4: Dip Switch

    INSTALLATION DIP SWITCH active low active high DIP 1 MONITORING Switch to CRITICAL when external disturbances are likely to DIP 2 ENVIRONMENT critical* standard cause unwanted detections. Switch to OFF when there is no background DIP 3 BACKGROUND (e.g. glass floor). DIP 4 OUTPUT CONFIGURATION DIP 5 (NOT USED) * When DIP2 is OFF (critical environments), testbody CB (DIN 18650-1) might not be detected.

  • Page 5: Push Buttons

    PUSH BUTTONS Quickly press twice to activate or deactivate the visible laser spots Press for 2 seconds to launch a teach-in process Press for 3 seconds to confirm the setting after changing the DIP switch to acknowledge the 6x flashing error message and confirm that you Press for 5 seconds want the sensor to be mounted higher than 4m.

  • Page 6: Front Face

    DETECTION ZONE SETTING & TEACH-IN Set the detection range either automatically or with the remote control: Automatic teach-in To launch a teach-in, press shortly (< 2 sec) the push button (or by remote control The sensor starts flashing red-green quickly and automatically learns the installation height. Wait until the sensor flashes green.

  • Page 7: Parameter Settings

    PARAMETER SETTINGS WIDTH DETECTION (right) FIELD no field HEIGHT no field WIDTH (left) A new teach-in overwrites no field these values. In order to change these settings by remote control, adjust DIP-switch 4 to ON. OUTPUT CONFIGURATION R1 (RELAY) R1 (RELAY) NO POWER NO POWER NO DETECTION...

  • Page 8: How To Use The Remote Control

    HOW TO USE THE REMOTE CONTROL After unlocking, the red LED If the red LED flashes quickly after unlocking, you To end an adjustment session, flashes and the sensor can need to enter an access code from 1 to 4 digits. always lock the sensor.

  • Page 9: Service Mode

    LED ACTIVATION/DEACTIVATION enable/ disable the LED when there is a detection. VISIBLE SPOTS turn on/ off the visible spots. SERVICE MODE disable the output and LED for during 15 minutes and can be useful during an installation, a mechanical teach-in of the door or maintenance work.

  • Page 10: Troubleshooting

    TROUBLESHOOTING In case of unwanted reactions of the door, verify whether the problem is caused by the sensor or the controller. To do so, activate the service mode (no safety) and launch a door cycle. If the door cycle is completed successfully, check the sensor.
  • Page 11 TROUBLESHOOTING The ORANGE LED is on The sensor encounters a Send the sensor back for a technical check-up. permanently. memory problem. The ORANGE LED flashes DIP-switch setting awaiting Corfirm the DIP-switch setting: long push on the push quickly. confirmation. button. The ORANGE LED flashes The sensor signals an Cut and restore power supply.

  • Page 12: Technical Specifications

    Specifications are subject to change without prior notice. All values are measured in specific conditions. BEA SA | LIEGE Science Park | ALLÉE DES NOISETIERS 5 - 4031 ANGLEUR [BELGIUM] | T +32 4 361 65 65 | F +32 4 361 28 58 | INFO@BEA.BE | WWW.BEA-SENSORS.COM BEA hereby declares that the equipment type Flatscan REV-PZ is in compliance with European Directives 2006/42/EC (Machinery), 2011/65/EU (RoHS) and 2014/30/EU (EMC).
