BEA LZR-WIDESCAN User Manual

Motion, presence, and safety sensor for industrial doors
Hide thumbs Also See for LZR-WIDESCAN:
Table of Contents

Advertisement

Quick Links

See also: Manual

DESCRIPTION

1
2
3
4
5
1.
main connector
2.
protection film
3.
laser window
4.
USB cap
5.
LED display
6.
cover
7.
cover lock
8.
cable passage
75.5916.02 LZR-WIDESCAN 20180112
75.5916.02 LZR-WIDESCAN 20180112
75.5916.02 LZR-WIDESCAN 20180112
75.5916.02 LZR-WIDESCAN 20180112
9.
LCD screen
10. keypad
11. tilt angle adjustment screw (1)
12. parallel angle adjustment screw (2)
13. lateral angle lock screw (1)
14. mounting bracket
LZR
-WIDESCAN
®
Motion, Presence, and Safety Sensor
for Industrial Doors
(US version)
6
7
8
9
10
11
12
13
14
