shows a timestamped version of all the reads and writes to the
registers.
Table 4. Example Scripting Operations
Command
WriteMem (phase_a/safeside_mmr/safe-
side_mmr:SCRATCH, 0x12)
ReadMem (phase_c/safeside_mmr/safe-
side_mmr:STATUS1)
Wait (2000m)
Import (Saved_Script)
Dialog ("message")
7. For documentation, detailed information about the selected
registers can be viewed in two ways: click the Info button in
the Interact section or use the dropdown menu in the Script-
ing/Documentation section.
8. For searching, go to the Find section for a few ways to filter
through the register map:
Use the two search bars in the Find section for quick navi-
►
gation. The Tab and Shift + Tab shortcuts can be used to
switch between the search bars.
To search the entire register map for all four phases, launch
►
the Search dialog from the top left corner of the Find sec-
tion. This feature supports regular expressions too.
analog.com
Description
Write 0x12 to the
Phase A SCRATCH
register
Read the Phase C
STATUS1 register
Wait for 2000 ms
Insert a saved script
named Saved_Script
Pop up dialog box with
message
