LED Signals
Signal
Red LED stays lit for 20
seconds after trigger is
released.
LED will flash for 20 sec. after
trigger is released.
Slow flashing light for 20 sec.
at end of cycle.
Fast flashing light for 20 sec.
20 sec. steady light then 20
sec flashing after tool cycle
Tool makes alert sound, both
red and white LEDs flash 1
time.
Tool makes alert sound, both
red and white LEDs flash 3
times.
Signal
Blue light flashes. Green remains off.
Blue light solid. Green remains off.
Green light flashes and blue light is solid.
Green and blue lights both flash.
Green and Blue LEDs solid.
10
Table 1: Tool LED Signals
Red LED White LED Sound
20 sec
2x
20 sec/2 Hz
20 sec/5 Hz
20 sec
20 sec
1x
1x
3x
3x
Table 2: Remote LED Signals
Green LED
© 2023 Greenlee Tools, Inc.
Meaning
Battery Charge Low
Motor Current Exceeds
20A During Cycle
Tool is Overheated
Internal Error
Tool Overheating
Battery Flat
Error: Necessary oil pressure for
auto-retract is not reached, or there
is manual retraction with the motor
not running.
For crimping: Crimp is not complete.
Error: Necessary oil pressure for
auto-retract is not reached with the
motor running.
For crimping: Crimp is not complete.
Blue LED
Wireless Signal Found & Paired
(Only for products equipped with end position sensor)
EK425LXR
Action
Change or charge the
battery.
Allow tool to cool before
continuing.
Send in for service.
Allow tool to cool before
continuing.
Change or charge the
battery.
Inspect workpiece/crimp
is within tool capacity or
wait for ram to fully retract
before starting new cycle.
Use manual retract to
open tool head and
remove workpiece. Inspect
workpiece/crimp is within
tool capacity.
Meaning
Searching for Wireless Signal
Tool Head is Moving
Remote Battery is Low
Cut is Complete
300100034 REV 00
