UG-1951

EVALUATION BOARD SOFTWARE

INSTALLING THE ACE SOFTWARE, ADMV8052
PLUG-INS, AND DRIVERS
The ADMV8052-EVALZ uses the Analog Devices ACE software.
For instructions on how to install and use the ACE software, go
to the ACE software page.
If the ACE software is already installed on the PC, ensure that
the installed ACE software is the latest version, as listed on the
ACE software page. If the installed software is not the latest
version, take the following steps to install the updated ACE
software:
1. Uninstall the current version of the ACE software on the PC.
Delete the ACE folder found in C:\ProgramData\Analog
2.
Devices and C:\Program Files (x86)\Analog Devices.
3. Install the latest version of the ACE software. During the
installation, ensure that the .NET 40 Client, SDP Drivers, and
LRF Drivers components are selected (see Figure 3).
Figure 3. Required Driver Installations with the ACE Software
Once the installation finishes, the ADMV8052 Board plug-in
appears in the Attached Hardware section of the Start tab
when the ACE software is running. (see Figure 4).
Figure 4. ADMV8052 Board Plug-In Window after Opening the
Rev. 0 | Page 4 of 18
EVAL-ADMV8052 User Guide
ACE Software
