Max 1700FS Quick Install Manual

Fail safe slide gate operator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Install Guide for
MAX 1700FS
Fail Safe Slide Gate Operator
CONFORMS TO UL STD 325
UL CLASS - I, II, III, IV
SAFETY SENSORS REQUIRED
CERTIFIED TO CAN/CSA STD
C22.2 NO. 247
Residential/Commercial
Brushless DC Slide Gate Operator
Made in USA
4009963
www.max.us.com
Version 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1700FS and is the answer not in the manual?

Questions and answers

Related Manuals for Max 1700FS

Summary of Contents for Max 1700FS

  • Page 1 Quick Install Guide for MAX 1700FS Fail Safe Slide Gate Operator CONFORMS TO UL STD 325 UL CLASS - I, II, III, IV SAFETY SENSORS REQUIRED CERTIFIED TO CAN/CSA STD C22.2 NO. 247 Residential/Commercial Brushless DC Slide Gate Operator Made in USA 4009963 www.max.us.com...

  • Page 2: Table Of Contents

    - 50 ft Max Gate Weight: 1700 lbs Level Gate; Not recommended for Inclined Gate Opening Time - Selectable speed control (MAX - 12 inch per second) Cycles per Hour AC Power - Continuous Battery Back-Up Cycles (Batteries fully charged) - Approximately 100 cycles...

  • Page 3: Operator Placement (Standard)

    MAX 1700FS Slider www.max.us.com The MAX 1700FS is a Fail Safe slide gate operator. The gate can be pushed open manually when the MANUAL RELEASE switch is turned ON. See page 10 for more information about this feature. Operator Placement (standard) The gate must be properly installed and work freely in both directions prior to installation of the gate operator.

  • Page 4: Connect Chain To Gate

    13.5” 13.5” Concrete Pad 6” DO NOT mount chain Note: See manual when Connecting chain Operator in Front Position (Standard) bracket too high on gate. with operator mounted in REAR Position. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 5: Ac Input Power

    T u r IMPORTANT: IMPORTANT: LEDs should light up on operator. Remove breather pin Battery power automatically turns ON. from gear reducer I O N BEFORE cycling DO NOT CYCLE OPERATOR! operator. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 6: Ground Operator

    NO LIMIT SWITCH / 24VDC STATUS CLAMP SLIPPING CLOSE LIMIT BATTERY SWITCH IN USE ON-LINE MOTOR POWER ON-LINE PRIMARY GATE GATE NOTE: See manual for more information about Matrix 1 settings. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 7: Program Virtual Limit Sensors

    The POSITION RECORDER LED will turn OFF, the GATE STATUS OPEN LED will turn ON and stay on and the beeping will stop. Virtual OPEN limit is programmed. Push CLOSE button and the operator will function normally. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 8: Entrapment Protection Wiring

    Monitored Normally Closed Type. NOTE: Photo input on Matrix 1 is NOT MONITORED (Normally OPEN) and is Inside Property NOT UL 325 entrapment protection. Continued on next page. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...
  • Page 9 If a self-supporting post is being used, then sensing edges need to be installed on EACH side of the post to protect against entrapment in the OPENING and CLOSING direction of gate travel. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 10: Adjust Erd Reverse Sensor

    LIMIT ti vi o st BATTERY ty B o o st SWITCH ON-LINE IN USE MOTOR POWER ON-LINE PRIMARY GATE GATE UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 11: Matrix 1 Settings

    2nd click clockwise: 1 sec... MOTOR POWER ON-LINE 3rd click: 4 sec... PRIMARY GATE GATE 4th click: 8 sec... etc up to 60 sec. MAX. See manual for more info. wiring opening device options MATRIX 1 maglock option BATTERY PRIMARY BACK-UP MODE...

  • Page 12: Manual Release

    Sold Separately OverLoad MC-200 Entrap ON-LINE LEFT RIGHT Motor Controller Sensitivity Connect to Jog RT or Jog Left depending on opening direction of gate. N.O. Install inside or outside of property. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 13: Dual Gate Operators Wiring

    MOTOR MOTION STOP OPEN CLOSE NOTE: The Alarm Shut-Off is located on the Primary gate operator ONLY. Matrix 1 There is NO alarm shut-off button on the secondary gate operator. STOP Button UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 14: Troubleshooting

    Fri 07/11/2014 10:56:33 ENTRAP : PRI_MC: Photo Cell Ac vated 1. Plug MAX USB flash drive into OBD port of Matrix 1. OBD LED will flash while file is downloading. l a s Remove flash drive after LED stops flashing (up to 5 minutes to download file).

  • Page 15: Gate Cycling Troubleshooting

    Check if any loops are active, check SAFETY LOOP or EXIT LOOP LED is ON. • Check if any open command inputs are active (check if LED is ON on the matrix 1 for: RADIO, FIRE DEPT, MAX OPEN, STRIKE, KEYPAD/RDR, PHOTOCELL). Check device connected to the input that LED light is turned ON.

  • Page 16: Matrix 1 Led Troubleshooting

    Sensor is NOT a N.C. monitored sensor that is UL325 2016 compliant. • Sensor on EDGE 2 is damaged or malfunctioning. • Sensor might need to be re-learned. Table continued on next page UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...
  • Page 17 • Check for a short in wiring to connected device. DO NOT power external keypads or telephone entry to 4 or 5 this port (only use for radio receiver / photocell). UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...

  • Page 18: Mc-200 Led Troubleshooting

    Problem Condition Problem Condition “POWER” LED is OFF • Check if AC POWER ON/OFF SWITCH (on MAX toroid box) is ON. • Check if power cable is plugged into back of MC-200 “Power In” input. “MATRIX ON-LINE” LED is OFF •...

  • Page 19: Bc-7 Module Led Troubleshooting

    Megatron Toroid Box AC POWER Switch is turned ON. To turn OFF ALL POWER to operator: 1. Turn OFF AC POWER Switch on MAX Megatron Toroid Box. Battery power remains ON. BATTERY Plug: 2. WAIT for 15 seconds.

  • Page 20: Commonly Used Safety Sensor Wiring

    L it y Wire motor controller GND to p e r R I M instead. a l o photocell COM (Energized) 5. Align photocell to reflector 6. Adjust sensitivity UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...
  • Page 21 MUST jumper ATTENTION: Voir la notice d’installation. unused inputs entrapment protection device MUST be MONITORED by the gate operator. Jumper UNUSED Entrapment Protection Inputs to GND or a fault will occur. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...
  • Page 22 Protection Inputs to GND or NOTE: To meet the UL 325 2016 standard, Type B1 Non-Contact sensor a fault will occur. entrapment protection device MUST be MONITORED by the gate operator. UL 325 2016 Standard-MAX 1700FS Quick Install Rev 3...
  • Page 23 MONITORED by the MAX gate operator. LEARN buttons for 3 seconds. The LEDs will blink rapidly and See your chosen Max operator manual to program the MAX motor then go into “fault” mode. Repeat the programming steps above. controller to “Learn” Edge 2 if desired.
  • Page 24 CONFORMS TO UL STD 325 UL CLASS - I, II, III, IV SAFETY SENSORS REQUIRED CERTIFIED TO CAN/CSA STD C22.2 NO. 247 Residential/Commercial Brushless DC Slide Gate Operator Made in USA 4009963 Maximum Controls LLC. 10530 Lawson River Ave...
