Internal I/O Connectors
Expansion Slots
X
X
Please follow the steps below to install the card into the socket.
User's Manual | ADS310-R680E/Q670E
Step 1:
Insert the card into the socket
at an angle while making sure
the notch and key are perfectly
aligned.
Step 2:
Press the end of the card far
from the socket down until
against the stand-off.
Step 3:
Screw tight the card onto the
stand-off with a screw driver
and a stand-off screw until
the gap between the card and
the stand-off closes up. The
card should be lying parallel to
the board when it's correctly
mounted.
Internal I/O Connectors
X
Battery
CPU_FAN
1
VGA
HDMI
+12V Power
LGA 1700
DP++
DP++
2.5G LAN 1
USB3_1/2
USB2_1/2
2.5G LAN 2
USB3_3/4
USB2_3/4
10G LAN 1
10G LAN 2
USB 3 10/9/8/7
M.2 M Key
Mic-in
M2CN4
Line-out
Line-in (opt.)
1
JP31
PCIE1 (PCIe x16)
PCIE2 (PCIe x4)
Front LAN
LED
1
2
SPI
SMBus
1
2
PCIE3 (PCIe x4)
5
7
8
USB3_5/6
USB2_5/6
2
TSJP3
TSJP8
TSJP6
1
10
Front Audio
2
6
2
6
2
6
2
6
2
6
2
6
1
9
PCIE4 (PCIe x4)
1
5
1
5
1
5
1
5
1
5
1
5
20
11
TSJP4
TSJP2
TSJP7
6
5
6
5
TSJP5
TSJP1
1
JP29/30/28
2
1
2
1
2
2
1
8
1
1
9
1
1
9
1
10
2
10
1
1
1
S/PDIF
DIO
DIO
SYS_FAN1 COM1
COM2 USB2_13
Power
USB2_11/12
The lithium ion battery addendum supplies power to the real-time clock and CMOS memory
as an auxiliary source of power when the main power is shut off. Insert a coin cell battery into
the holder and make sure the polarities are correctly oriented — the cap side (rimmed rounded
edge) is negative and should be facing the holder; the flat side with a + mark is positive and
should be facing away from the holder.
Safety Measures
• There exists explosion hazard if the battery is incorrectly installed.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to local ordinances.
Chapter 2
HARDWARE INSTALLATION
1
SYS_FAN3
„ Battery
Battery
ATX Power
1
2
Front Panel
11
InnoAGE HDR1
1
2
5
6
1
SYS_FAN2
13
J36
eSPI
Intel
JP25
JP5
1
1
2
1
JP26
1
1
SOJ1
1
R680E/Q670E
9
PS/2
1
JP33
2
1
JP32
1
M.2 M Key
M2CN3
CN1
M.2 E Key
1
M2CN2
1
1
1
1
1
2
SATA0(R4)/SATA1(R5)/SATA2(R6)/SATA3(R7)
32
