CB 1-w Solar Tower
Admin Guide
Solar Audio Paging Amplifier Wiring
Incoming
This harness comes with the Amp PCB
Neg
12V DC Power
SPKR -
SPKR +
This harness comes with the Amp PCB
360°Audio Paging
System
Product wiring diagram shown reasonably represents current offering and is intended to assist in component identification and service. Earlier product
production may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact
manufacturer to confirm replacement part version and availability.
