Speakerphone Installation

Installation of IP Faceplate Speakerphone - If not previously installed from the factory, your
IP Faceplate Speakerphone should appear as displayed in the photo below. Once connected,
it needs to be secured to the CB 1-w tower using the 6 countersunk security screws and
security bit included with the unit. See LS1000 VoIP Speakerphone Admin Guide for
programming details.

Pre-Installed Components

Solar Power Controller - All of the wires connected to the solar power controller are pre-
installed at the factory as shown in the photo below, located behind the upper access door
of the tower. Note the 3 circuit breakers are OFF.
wires connected. Turn the Battery circuit breaker on first, then the Panel, then the Load.
Cellular Communication Components - If your unit was ordered with 4G/5G/LTE Cellular
Communication, the components required to operate this system are pre-installed at the
factory as shown in the photo below located behind the upper access door of the tower.
Please note, service need to be activated upon install by contacting Code Blue Tech
Support.
Cellular Communication
Equipment
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186
CB 1-w Solar Tower
Once the batteries are installed and all
Solar Power
Controller
