PROGRAMMING PRIMARY & SECONDARY MODES
1. Remove power from unit.
2. Short the Yellow wires together.
3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short. The unit will
alternately demonstrate the Secondary-Flash Mode and Primary-Steadyburn Mode that will be displayed during operation. For
approximately 4 seconds the Secondary-Flash Mode will be demonstrated, followed by the Primary-Steadyburn Mode.
4. To select the next mode of operation, momentarily short the yellow wires. The unit will cycle to the next mode in the list above.
5. There are seven Flash Modes and three Steadyburn Modes combinations to choose from.
6. When you reach the desired mode of operation, remove power from the unit. You MUST leave power disconnected for 20 seconds
BEFORE reapplying. When power is reapplied, the unit will operate as programmed above.
NOTE: If you do not leave power disconnected for 20 seconds before reapplying power, the light will default to Program Mode.
INPUT VOLTAGE RANGE: 12-24V AC or DC
TEMPERATURE RATING: -40°C to +65°C (-40°F to 149°F)
TYPICAL POWER CONSUMPTION AT 25°C
Voltage Flash Mode
12V DC
24V DC
12V AC
24V AC
NOTE: Average current draw in Flash Mode will vary by selected Flash mode. The above maximum amperage draw is
stated at Single 60 FPM.
Code Blue • 259 Hedcor Street
Mode Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
0.24 A Max
0.12 A Max
1.1 A rms Max
0.22 A rms Max
• Holland, MI 49423 USA • 800.205.7186
CB 1-w Solar Tower
Primary-Steadyburn Mode
High
OFF
Low
High
OFF
Low
High
OFF
Low
High
OFF
Low
High
OFF
Low
High
OFF
Low
High
OFF
Low
Steady Mode - High
0.24 A
0.12 A
0.53 A rms
0.22 A rms
• www.codeblue.com
Admin Guide
Secondary-Flash Mode
Single - 60 FPM
Single - 60 FPM
Single - 60 FPM
Single - 150 FPM
Single - 150 FPM
Single - 150 FPM
Single - 375 FPM
Single - 375 FPM
Single - 375 FPM
Neobe - 75
Neobe - 75
Neobe - 75
Neobe - 150
Neobe - 150
Neobe - 150
Double - 125
Double - 125
Double - 125
Double - 250
Double - 250
Double - 250
GU-168-E
