User Manual
AD001H
Operation Controls and Function
Button Function:
MENU: OSD ON
EXIT: OSD OFF
  Decrease / increase
OSD Menu
BRIGHTNESS
CONTRAST
SATURATION
HUE
SHARPNESS
RESOLUTION

Button Function: Up / Down
Features Menu
BRIGHTNESS
CONTRAST
SATURATION
HUE
SHARPNESS

Button Function: Select feature setup for decrease / increase, press MENU for next function
Resolution
Press  to select resolution.
640X480
800x600
1024x768
1280x1024
After setup, press Exit will be auto save and turn off OSD mode.
Remark
1. If there is no any adjustment under OSD mode, OSD will auto turn off after 20 seconds.
2. OSD function only display on VGA output mode.
3. Initialize factory default value.: Unplug the power adaptor, then press Exit button and plug the power
adaptor.
NOTE: Wrong Resolution setting will cause the picture not display, please initialize factory default value.
