- Page 1 User Manual DT3326 Barcodescanner – DT3326 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 22-1-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3326’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3326’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3326’ Symbologies ........................23 2.5.1 1D all symbologies ....................24 2.5.2 2D all symbologies ....................24 2.5.3 Inverse barcode ....................24 2.5.4 All barcodes ......................24 2.5.5 EAN8 Settings ....................... 24 2.5.6 Code 11 Settings ....................25 2.5.7 Add-on code setting ..................... 26 2.5.8 EAN 13 settings .....................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3326’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3326’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Beeper Duration
User manual ‘DT3326’ Enable Illumination Disable Illumination Always off Always on 2.1.5 Beeper Duration Short Normal 2.7Khz Mute 2.1.6 Beeper settings Volume set to High (50%) (default) Volume set to midrange (25%) Volume set to bass (12.5%) Datum : feb-2024 pagina 8 van 47 Versie : 1.0... -
Page 9: Set The Beep Switch
User manual ‘DT3326’ 2.1.7 Set the beep switch Open (default) Close 2.1.8 Power on beep switch Open (default) Close 2.1.9 Read success beep switch Open (default) Close 2.2 Reading mode settings 2.2.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. -
Page 10: Continuous Mode (Default)
User manual ‘DT3326’ 2.2.2 Continuous mode (default) When the reading setting code is switched to this mode, it enters the continuous reading state. In this mode, the "repeat read switch" can be used to prevent the same barcode from being read more than once. - Page 11 User manual ‘DT3326’ Short time (3s) In time (7s) Long time (10s) Valid only in "Level Trigger Mode" and "Pulse Trigger Mode". Datum : feb-2024 pagina 11 van 47 Versie : 1.0...
-
Page 12: Communication Settings
User manual ‘DT3326’ 2.3 Communication settings 2.3.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC Enable virtual keyboard Disable virtual keyboard 2.3.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Datum : feb-2024 pagina 12 van 47 Versie : 1.0... -
Page 13: Usb Keyboard Sending Speed
User manual ‘DT3326’ Spanish (Brazil) Portuguese Portuguese (Brazil) French German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America 2.3.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 14: Set Usb Keyboard Sending Speed
User manual ‘DT3326’ 2.3.4 Set USB keyboard sending speed USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time range: 0ms~200ms. Set USB keyboard sending speed Setting the USB keyboard to send speed of 50ms can be set by reading the following barcodes in order. -
Page 15: Serial Port Baud Rate Setting
User manual ‘DT3326’ Stop bit 1 Stop bit 2 Check bit O Check bit N Check bit E 2.3.7 Serial port baud rate setting Baud rate 4800 Baud rate 9600 (default) Baud rate 19200 Baud rate 38400 Baud rate 57600... -
Page 16: Serial Port Output
User manual ‘DT3326’ 2.3.8 Serial port output UTF-8 Serial output according to barcode content 2.3.9 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.4 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. -
Page 17: Customized Prefixes
User manual ‘DT3326’ "AB123". After the barcode reading data is "123", the scanner will add the string "AB" before the string "123", and the host side will receive "AB123". If set to "Off", the decoded information will only have the barcode data information, no prefix, and the default value is to turn off the custom prefix output. -
Page 18: Custom Suffixes
User manual ‘DT3326’ Enable Disable (default) Clear all custom suffixes Output all 2.4.4 Custom suffixes Custom suffix adds a user-defined string after the decoded information, and the output format after customization is "barcode content + custom content". Set the custom suffix to 'a' (the hex value of a is 0x61) 1. -
Page 19: Customize Code Id
User manual ‘DT3326’ Disable CODE ID (default) Code ID prefix Code ID suffix Clear all custom Code IDs 2.4.6 Customize Code ID Please refer to the following example for how to modify the Code ID. Modify the Code ID of Codabar (Code ID:0x61) to "Y" (hexadecimal value 0x59). - Page 20 User manual ‘DT3326’ No terminator Enter (default) Line Feed (Down) Carriage return + Line feed (Enter+Down) Datum : feb-2024 pagina 20 van 47 Versie : 1.0...
-
Page 21: Ctrl + X
User manual ‘DT3326’ 2.4.8 CTRL + X Non- printable Keyboard Control + ASCII ( CTRL+ X) Mode ASCII control characters Windows Mode Control + X Control + X Mode Off Mode On CTRL + X Char CTRL + X function... -
Page 22: Case Output Settings
User manual ‘DT3326’ CTRL+ T CTRL+ U CTRL+ V Paste CTRL+ W CTRL+ X CTRL+ Y CTRL+ Z CTRL+ [ CTRL+ \ CTRL+ ] CTRL+ ^ CTRL+ - NP Enter 2.4.9 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. -
Page 23: Data Output Settings
User manual ‘DT3326’ 2.4.10 Data output settings OPMERKING: The prefix and suffix are not processed, and the prefix and suffix are output normally. Raw data output (default) Front-end data output Intermediate data output Back-end data output Start and end data output 2.4.11 Pre/Post data length setting... -
Page 24: All Symbologies
User manual ‘DT3326’ 2.5.1 1D all symbologies Enable Disable 2.5.2 2D all symbologies Enable Disable 2.5.3 Inverse barcode Decode regular only Decode inverse only 2.5.4 All barcodes Close all barcodes Turn on all barcodes 2.5.5 EAN8 Settings EAN8 on (default) -
Page 25: Code 11 Settings
User manual ‘DT3326’ Enable EAN8 transmission Check Character Disable EAN8 transmit Check Character (default) Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.5.6 Code 11 Settings Enable Disable 1 check bit 2 check bits Transmit check bit... -
Page 26: Add-On Code Setting
User manual ‘DT3326’ 2.5.7 Add-on code setting Adaptive UPC/EAN add-on codes Only Decode UPC/EAN Add-on codes Ignore UPC/EAN add-on codes (default) 2.5.8 EAN 13 settings EAN13 on (default) EAN13 off 2.5.9 ISSN Settings Convert EAN-13 to ISSN Do not Convert EAN-13 to ISSN (default) 2.5.10 ISBN setting... -
Page 27: Upc-A Settings
User manual ‘DT3326’ 2.5.11 UPC-A settings Transmit UPC-A check character (default) Do not Transmit UPC-A check character Convert UPC-A to EAN13 (default) Do not Convert UPC-A to EAN13 Enable Disable Output digital Not output digital 2.5.12 UPC-E settings UPC-E on (default) -
Page 28: Upce
User manual ‘DT3326’ Convert UPC-E to UPC-A Do not Convert UPC-E to UPC-A (default) 2.5.13 UPCE Enable Disable 2.5.14 EAN/UPC Enable Disable 2.5.15 Code 39 Settings Code 39 on (default) Code 39 Off Datum : feb-2024 pagina 28 van 47... -
Page 29: Code 39 Length Setting
User manual ‘DT3326’ Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character Transmit Code 39 Check Character (default) Full ASCII On Full ASCII Off (default) 2.5.16 Code 39 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 30: Code 32 Settings
User manual ‘DT3326’ 2.5.17 Code 32 settings Convert Code39 to Code32 Do not Convert Code39 to Code32 (default) 2.5.18 Code 128 settings Code 128 on (default) Code 128 Off 2.5.19 Code 128 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 31: Code 93 Settings
User manual ‘DT3326’ 2.5.20 Code 93 settings Code 93 On (default) Code 93 Off 2.5.21 Code 93 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 32: Codabar Length Setting
User manual ‘DT3326’ Transmit Codabar start and stop characters Do not Transmit Codabar start and stop characters (default) Not check Enable check transmit check bit 2.5.23 Codabar Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 33: Gs1 Databar Limited
User manual ‘DT3326’ 2.5.24 GS1 Databar Limited Enable Disable 2.5.25 GS1 Databar omnidirectional Enable Disable 2.5.26 GS1 Databar Expanded Enable Disable 2.5.27 Data matrix Code Enable Disable 2 of 5 enable 2 of 5 disable Datum : feb-2024 pagina 33 van 47... -
Page 34: Msi
User manual ‘DT3326’ Matrix 2 of 5 check bit enable Matrix 2 of 5 check bit disable 2.5.28 MSI Enable Disable 2.5.29 QR Enable Disable 2.5.30 Micro QR code Enable Disable Datum : feb-2024 pagina 34 van 47 Versie : 1.0... -
Page 35: Pdf417
User manual ‘DT3326’ 2.5.31 PDF417 Enable Disable 2.5.32 Micro PDF417 Enable Disable 2.5.33 RSS-Expanded Enable Disable 2.5.34 RSS-Limited Enable Disable Datum : feb-2024 pagina 35 van 47 Versie : 1.0... -
Page 36: Rss-14
User manual ‘DT3326’ 2.5.35 RSS-14 Enable Disable 2.5.36 Straight 2 of 5 Industrial Enable Disable 2.5.37 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character... -
Page 37: Aztec Code
User manual ‘DT3326’ 2.5.38 Aztec code Enable Disable 2.5.39 ITF25 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 38: Appendix
User manual ‘DT3326’ 3. Appendix 3.1.1 ASCII Character table <SPACE> “ & ‘ Datum : feb-2024 pagina 38 van 47 Versie : 1.0... - Page 39 User manual ‘DT3326’ < > Datum : feb-2024 pagina 39 van 47 Versie : 1.0...
-
Page 40: Function Key Mapping Table
User manual ‘DT3326’ 3.1.2 Function Key Mapping Table Key（Control Character Key（Control Character Escape Escape Disabled） Enabled） Save Ctrl+@ Insert Ctrl+A Home Ctrl+B Ctrl+C Delete Ctrl+D PageUp Ctrl+E PageDown Ctrl+F Ctrl+G Backspace Ctrl+H Ctrl+I Enter Ctrl+J Caps Lock Ctrl+K Print Screen... - Page 41 User manual ‘DT3326’ ↓ Ctrl+R ← Ctrl+S → Ctrl+T Ctrl+U Ctrl+V Ctrl+W Ctrl+X Ctrl+Y Ctrl+Z Ctrl+[ Ctrl+\ Ctrl+] Ctrl+^ Ctrl+_ Datum : feb-2024 pagina 41 van 47 Versie : 1.0...
-
Page 42: Control Character Set
User manual ‘DT3326’ 3.1.3 Control Character Set Datum : feb-2024 pagina 42 van 47 Versie : 1.0... - Page 43 User manual ‘DT3326’ Datum : feb-2024 pagina 43 van 47 Versie : 1.0...
-
Page 44: Barcode Id Table
User manual ‘DT3326’ 3.1.4 Barcode ID Table Symbologies CODE ID(default) All Symbologies Codabar Code128 Code32 < Code93 Code39 Code11 EAN-13 EAN-8 GS1 DataBar GS1-128 (EAN-128) 2 of 5 Interleaved 2 of 5 Matrix 2 of 5 Industry 2 of 5/IATA... - Page 45 User manual ‘DT3326’ Aztec Code DataMatrix PDF417 Micro PDF417 QR Code Micro QR Code Datum : feb-2024 pagina 45 van 47 Versie : 1.0...
-
Page 46: Aim Id Table
User manual ‘DT3326’ 3.1.5 AIM ID table Symbolgoies AIM ID Description Codabar m：0~1 Code128 m：0，1，2，4 Code32 Code93 Code39 m：0，1，3，4，5，7 Code11 m：0，1，3，8，9 EAN-13 / EAN-8 m：0，1，3，4 GS1 DataBar GS1-128 (EAN-128) Interleaved 2 of 5 m：0，1，3 Matrix 2 of 5 Industry 2 of 5/IATA UPC-A/ UPC-E m：0，3... - Page 47 User manual ‘DT3326’ QR Code / Micro QR Code m: 0~6 Datum : feb-2024 pagina 47 van 47 Versie : 1.0...
