- Page 1 User Manual DT3327 Barcodescanner – DT3327 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 23-8-2023 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3327’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3327’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3327’ 3.1.2 Appendix 3 Control Characters Table ..............20 3.1.3 Appendix 4 ASCII Code table ................20 4. APPENDIX D – FUNCTION KEY TABLE ..................51 5. APPENDIX D – FUNCTION KEY TABLE ................... 52 1. APPENDIX D – FUNCTION KEY TABLE ..................52...
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3327’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3327’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Com Port
User manual ‘DT3327’ Volume set to High (50%) (default) Volume set to midrange (25%) 2.1.5 Com Port Virtual RS232 2.2 Reading mode settings 2.2.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. -
Page 9: Communication Settings
User manual ‘DT3327’ 2.3 Communication settings 2.3.1 Communication settings USB HID (default) RS-232 serial port 2.3.2 Set USB keyboard USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time range: 0ms~200ms. Hide 2.3.3 Serial port baud rate setting... -
Page 10: Serial Port Parity Bit Setting
User manual ‘DT3327’ 2.3.4 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.4 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. will be added before and after the decoding information. "Custom suffix", "End suffix", etc. -
Page 11: Custom Suffix On/Off Settings
User manual ‘DT3327’ 2.4.2 Custom suffix on/off settings The custom suffix adds a user-defined string after the decoded information. For example, it is allowed to add a custom suffix and set the suffix to the string "AB", after reading the barcode with the data of "123", the scanner adds the string "AB"... -
Page 12: Symbologies
User manual ‘DT3327’ 2.5 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. The fewer barcode types that are turned on, the faster the scanner will Scan. You can turn off the barcode types that will not be used to improve the performance of the scanner. -
Page 13: Upc-E Settings
User manual ‘DT3327’ Convert UPC-A to EAN13 (default) Do not Convert UPC-A to EAN13 2.5.4 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) Character Convert UPC-E to UPC-A Do not Convert UPC-E to UPC-A (default) 2.5.5 Code 39 Settings... -
Page 14: Code 39 Length Setting
User manual ‘DT3327’ Do not Transmit Code 39 Check Character Transmit Code 39 Check Character (default) Do not Transmit Code 39 start and stop Transmit Code 39 start and stop characters characters (default) Full ASCII On Full ASCII Off (default) 2.5.6 Code 39 Length Setting... -
Page 15: Code 128 Settings
User manual ‘DT3327’ 2.5.7 Code 128 settings Code 128 on (default) Code 128 Off Enable Code 128 Check Character (default) Disable Code 128 Check Character 2.5.8 Code 128 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 16: Code 93 Settings
User manual ‘DT3327’ 2.5.9 Code 93 settings Code 93 On (default) Code 93 Off Enable Code 93 Check Character (default) Disable Code 93 Check Character 2.5.10 Code 93 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 17: Codabar Settings
User manual ‘DT3327’ 2.5.11 Codabar Settings Codabar on (default) Codabar Off Transmit Codabar start and stop characters Do not Transmit Codabar start and stop characters (default) 2.5.12 Codabar Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 18: Interleave 2 Of 5 (Itf5) Setting
User manual ‘DT3327’ 2.5.13 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character Do not Transmit ITF25 Check Charcter (default) 2.5.14 ITF25 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 19: Appendix
User manual ‘DT3327’ 3. Appendix 3.1 Appendix 1 Data code table 3.1.1 Appendix 2 Code system support list Datum : feb-2024 pagina 19 van 53 Versie : 1.0... - Page 20 User manual ‘DT3327’ 3.1.2 Appendix 3 Control Characters Table 3.1.3 Appendix 4 ASCII Code table Function Key Mapping Hexadecimal Decimal ASCII Ctrl Char Alt+Unicode Null Ctrl+@ Alt + 000 Home Ctrl+A Alt + 001 Ctrl+B Alt + 002 Up Arrow...
- Page 21 User manual ‘DT3327’ Enter Enter Enter Page Up Ctrl+N Alt + 014 Page Down Ctrl+O Alt + 015 Hexadecima Decimal ASCII SPACE " Datum : feb-2024 pagina 21 van 53 Versie : 1.0...
- Page 22 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 22 van 53 Versie : 1.0...
- Page 23 User manual ‘DT3327’ & Hexadecimal Decimal ASCII Datum : feb-2024 pagina 23 van 53 Versie : 1.0...
- Page 24 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 24 van 53 Versie : 1.0...
- Page 25 User manual ‘DT3327’ Datum : feb-2024 pagina 25 van 53 Versie : 1.0...
- Page 26 User manual ‘DT3327’ Hexadeci Decimal ASCII Datum : feb-2024 pagina 26 van 53 Versie : 1.0...
- Page 27 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 27 van 53 Versie : 1.0...
- Page 28 User manual ‘DT3327’ Hexadecima Decimal ASCII Datum : feb-2024 pagina 28 van 53 Versie : 1.0...
- Page 29 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 29 van 53 Versie : 1.0...
- Page 30 User manual ‘DT3327’ < > Datum : feb-2024 pagina 30 van 53 Versie : 1.0...
- Page 31 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 31 van 53 Versie : 1.0...
- Page 32 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 32 van 53 Versie : 1.0...
- Page 33 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 33 van 53 Versie : 1.0...
- Page 34 User manual ‘DT3327’ Hexadecima Decimal ASCII Datum : feb-2024 pagina 34 van 53 Versie : 1.0...
- Page 35 User manual ‘DT3327’ Datum : feb-2024 pagina 35 van 53 Versie : 1.0...
- Page 36 User manual ‘DT3327’ Hexadecima Decimal ASCII Datum : feb-2024 pagina 36 van 53 Versie : 1.0...
- Page 37 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 37 van 53 Versie : 1.0...
- Page 38 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 38 van 53 Versie : 1.0...
- Page 39 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 39 van 53 Versie : 1.0...
- Page 40 User manual ‘DT3327’ Datum : feb-2024 pagina 40 van 53 Versie : 1.0...
- Page 41 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 41 van 53 Versie : 1.0...
- Page 42 User manual ‘DT3327’ Hexadecima Decimal ASCII Datum : feb-2024 pagina 42 van 53 Versie : 1.0...
- Page 43 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 43 van 53 Versie : 1.0...
- Page 44 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 44 van 53 Versie : 1.0...
- Page 45 User manual ‘DT3327’ Datum : feb-2024 pagina 45 van 53 Versie : 1.0...
- Page 46 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 46 van 53 Versie : 1.0...
- Page 47 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 47 van 53 Versie : 1.0...
- Page 48 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 48 van 53 Versie : 1.0...
- Page 49 User manual ‘DT3327’ Hexadecimal Decimal ASCII Datum : feb-2024 pagina 49 van 53 Versie : 1.0...
- Page 50 User manual ‘DT3327’ Delete Datum : feb-2024 pagina 50 van 53 Versie : 1.0...
- Page 51 User manual ‘DT3327’ 4. Appendix D – Function Key Table Insert Delete Home Up Arrow Down Arrow Left Arrow Right Arrow Datum : feb-2024 pagina 51 van 53 Versie : 1.0...
- Page 52 User manual ‘DT3327’ 5. Appendix D – Function Key Table Shift Page Up Page Down 1. Appendix D – Function Key Table Datum : feb-2024 pagina 52 van 53 Versie : 1.0...
-
Page 53: Datum : Feb-2024 Pagina 3 Van
User manual ‘DT3327’ Datum : feb-2024 pagina 53 van 53 Versie : 1.0...
