- Page 1 User Manual DT3322 Barcodescanner – DT3322 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 26-8-2023 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3322’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3322’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3322’ 2.5.5 Settng ........................20 2.5.6 ISBN setting ......................20 2.5.7 UPC-A settings ...................... 20 2.5.8 UPC-E settings ...................... 20 2.5.9 Code 39 Settings ....................21 2.5.10 Code 39 Length Setting ..................21 2.5.11 Code 32 settings ....................22 2.5.12 Code 128 settings ....................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3322’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3322’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Beeper Settings
User manual ‘DT3322’ 2.1.5 Beeper settings Volume set to High (50%) (default) Volume set to midrange (25%) Volume set to bass (12.5%) 2.1.6 Set the beep switch Open (default) Close 2.1.7 Power on beep switch Open (default) Close 2.1.8 Read success beep switch... -
Page 9: Reading Mode Settings
User manual ‘DT3322’ 2.2 Reading mode settings 2.2.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. After reading the code successfully or releasing the trigger key, the code reading ends and the next decoding needs to re-enter the low level state. -
Page 10: One Read Timeout
User manual ‘DT3322’ Allow repeat readings (default) Repeat reading is not allowed 2.2.5 One read timeout One time reading timeout time, the unit is 0.1 seconds. The default value is 30 (3 seconds), when set to 0, it means that the device is always in the reading state, and the time range can be set: 0~999. -
Page 11: Communication Settings
User manual ‘DT3322’ 2.3 Communication settings 2.3.1 Communication settings USB HID (default) USB CDC serial port RS-232 serial port 2.3.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Spanish (Brazil) Portuguese Portuguese (Brazil) French German (Austria) -
Page 12: Usb Keyboard Sending Speed
User manual ‘DT3322’ Turkish F English (UK) Japanese German (Switzerland) 2.3.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 13: Control Characters
User manual ‘DT3322’ 4. Read "Save" (see data code table) 5. Read "Exit Settings" 2.3.5 Control Characters Specific reference to the control character table, only the data content of the barcode is converted. Off (default) Control + ASCII mode Alt + Keypad mode 2.3.6 Serial communication settings... -
Page 14: Serial Port Parity Bit Setting
User manual ‘DT3322’ 2.3.8 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.4 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. will be added before and after the decoding information. "Custom suffix", "End suffix", etc. -
Page 15: Customized Prefixes
User manual ‘DT3322’ 2.4.2 Customized prefixes The custom prefix adds a user-defined string before the decoded information, and the output format after customization is "Custom Content + Barcode Content". Set the custom prefix to 'a' (the hex value of a is 0x61) 1. -
Page 16: Custom Id Output Method
User manual ‘DT3322’ Set the custom suffix to 'a' (the hex value of a is 0x61) 1. Read "Startup Settings" 2. Read the "Custom Suffix" setting code 3. Check the ASCII code of the character "a": the ASCII code of "a" is "0x61" (see ASCII code table) 4. -
Page 17: Terminator Settings
User manual ‘DT3322’ 2. Read "Custom Code ID" 3. Check the Code ID of the barcode: the Code ID of "Codabar" is "0x61" (see the list of code system support) 4. Check the ASCII code of the character "Y": the ASCII code of "Y" is "0x59" (see ASCII code table) 5. -
Page 18: Case Output Settings
User manual ‘DT3322’ 2.4.8 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. Normal output (default) Convert Case Convert all to Uppercase Convert All to lowercase 2.5 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. -
Page 19: Add-On Code Setting
User manual ‘DT3322’ Enable EAN8 transmission Check Character Disable EAN8 transmit Check Character (default) Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.5.3 Add-on code setting Adaptive UPC/EAN add-on codes Only Decode UPC/EAN Add-on codes 2.5.4 EAN 13 settings... -
Page 20: Settng
User manual ‘DT3322’ 2.5.5 Settng 2.5.6 ISBN setting Set the ISBN data bits to 13 bits Set ISBN data bits to 10 bits (default) 2.5.7 UPC-A settings Transmit UPC-A check character (default) Do not Transmit UPC-A check character Convert UPC-A to EAN13 (default) Do not Convert UPC-A to EAN13 2.5.8 UPC-E settings... -
Page 21: Code 39 Settings
User manual ‘DT3322’ 2.5.9 Code 39 Settings Code 39 on (default) Code 39 Off Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character Transmit Code 39 Check Character (default) Do not Transmit Code 39 start and stop... -
Page 22: Code 32 Settings
User manual ‘DT3322’ Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 23: Code 93 Settings
User manual ‘DT3322’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 24: Codabar Settings
User manual ‘DT3322’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 25: Interleave 2 Of 5 (Itf5) Setting
User manual ‘DT3322’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" barcode 2. Scan "Minimum length setting" barcode 3. - Page 26 User manual ‘DT3322’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" barcode 2. Scan "Minimum length setting" barcode 3.
-
Page 27: Appendix
User manual ‘DT3322’ 3. Appendix 3.1 Appendix 1 Digital Barcodes Datum : feb-2024 pagina 27 van 35 Versie : 1.0... - Page 28 User manual ‘DT3322’ Save Cancel Delete All Digits Delete Last Digit Datum : feb-2024 pagina 28 van 35 Versie : 1.0...
-
Page 29: Appendix 2 Symbologies
User manual ‘DT3322’ 3.1.1 Appendix 2 Symbologies Code ID Barcode Type Char Codabar 0x42 Code 11 0x68 Code 128 0x6A Code 39(Code 32) 0x62 Code 93 0x69 ISBN 0x53 ISSN 0x6E EAN-13(including ISBN) 0x64 EAN-8 0x44 GS1 DataBar 0x79 GS1 DataBar Limited... -
Page 30: Appendix 3 Control Characters Table
User manual ‘DT3322’ 3.1.2 Appendix 3 Control Characters Table ASCII Control + ASCII Alt + Keypad SOH (Start of Header) Ctrl+A Alt+001 STX (Start of Text) Ctrl+B Alt+002 ETX (End of Text) Ctrl+C Alt+003 EOT (End of Transmission) Ctrl+D Alt+004... -
Page 31: Appendix 4 Ascii Code Table
User manual ‘DT3322’ 3.1.3 Appendix 4 ASCII Code table Binary Decimal Char NUL (NULL) SOH (Start Of Headling) STX (Start Of Text) ETX (End Of Text) EOT (End Of Transmission) ENQ (Enquiry) ACK (Acknowledge) BEL (Bell) 1000 BS (Backspace) 1001... - Page 32 User manual ‘DT3322’ 10100 DC4 (Device Control 4) NAK (Negative 10101 Acknowledge) 10110 SYN (Synchronous Idle) ETB (End of Transmission 10111 Block) 11000 CAN (Cancel) 11001 EM (End of Medium) 11010 SUB (Substitute) 11011 ESC (Escape) 11100 FS (File Separator)
- Page 33 User manual ‘DT3322’ 110110 110111 111000 111001 111010 111011 111100 < 111101 111110 > 111111 1000000 1000001 1000010 1000011 1000100 1000101 1000110 1000111 1001000 1001001 1001010 1001011 1001100 1001101 1001110 1001111 1010000 1010001 1010010 1010011 1010100 1010101 1010110 1010111 1011000...
- Page 34 User manual ‘DT3322’ 1011011 1011100 1011101 1011110 1011111 1100000 1100001 1100010 1100011 1100100 1100101 1100110 1100111 1101000 1101001 1101010 1101011 1101100 1101101 1101110 1101111 1110000 1110001 1110010 1110011 1110100 1110101 1110110 1110111 1111000 1111001 1111010 1111011 1111100 1111101 1111110 1111111...
- Page 35 User manual ‘DT3322’ Datum : feb-2024 pagina 35 van 35 Versie : 1.0...
