- Page 1 User Manual DT3229 Barcodescanner – DT3229 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 2-2-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3229’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3229’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3229’ 2.5.3 Inverse barcode ....................22 2.5.4 All barcodes ......................23 2.5.5 EAN8 Settings ....................... 23 2.5.6 Code 11 Settings ....................23 2.5.7 EAN 13 settings ..................... 24 2.5.8 ISSN Settings ......................24 2.5.9 HANXIN ......................... 25 2.5.10 ISBN setting ......................25 2.5.11 UPC-A settings ......................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3229’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3229’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Led
User manual ‘DT3229’ 2.1.4 Led Enable Aimer Disable Aimer Enable Illumination Disable Illumination Always off Always on 2.1.5 Beeper Duration Short Normal 2.7Khz Mute Datum : feb-2024 pagina 8 van 42 Versie : 1.0... -
Page 9: Beeper Settings
User manual ‘DT3229’ 2.1.6 Beeper settings Volume set to High (50%) (default) Volume set to midrange (25%) Volume set to bass (12.5%) 2.1.7 Set the beep switch Open (default) Close 2.1.8 Power on beep switch Open (default) Close 2.1.9 Read success beep switch... -
Page 10: Reading Mode Settings
User manual ‘DT3229’ 2.2 Reading mode settings 2.2.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. After reading the code successfully or releasing the trigger key, the code reading ends and the next decoding needs to re-enter the low level state. -
Page 11: Auto Scan Mode
User manual ‘DT3229’ Low sensitivity 2.2.4 Auto Scan mode Auto scan Delay 50ms Delay 100ms Delay 300ms 2.2.5 Code reading timeout 30sec 300sec 2400sec 2.2.6 One read timeout One time reading timeout time, the unit is 0.1 seconds. The default value is 30 (3 seconds), when set to 0, it means that the device is always in the reading state, and the time range can be set: 0~999. - Page 12 User manual ‘DT3229’ Short time (3s) In time (7s) Long time (10s) Valid only in "Level Trigger Mode" and "Pulse Trigger Mode". Datum : feb-2024 pagina 12 van 42 Versie : 1.0...
-
Page 13: Communication Settings
User manual ‘DT3229’ 2.3 Communication settings 2.3.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC Enable virtual keyboard Disable virtual keyboard 2.3.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Datum : feb-2024 pagina 13 van 42 Versie : 1.0... -
Page 14: Usb Keyboard Sending Speed
User manual ‘DT3229’ Spanish (Brazil) Portuguese Portuguese (Brazil) French German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America 2.3.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 15: Set Usb Keyboard Sending Speed
User manual ‘DT3229’ 5 ms (default) 10 ms 20 ms 2.3.4 Set USB keyboard sending speed USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time range: 0ms~200ms. Set USB keyboard sending speed Setting the USB keyboard to send speed of 50ms can be set by reading the following barcodes in order. -
Page 16: Control Characters
User manual ‘DT3229’ 2.3.5 Control Characters Specific reference to the control character table, only the data content of the barcode is converted. Off (default) Control + ASCII mode Alt + Keypad mode 2.3.6 Serial port baud rate setting Baud rate 4800... -
Page 17: Serial Port Output
User manual ‘DT3229’ 2.3.7 Serial port output UTF-8 Serial output according to barcode content 2.3.8 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.4 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. -
Page 18: Hide 1 Character
User manual ‘DT3229’ 2.4.1 Hide 1 character Hide 1 from start Hide 1 from the end 2.4.2 Custom prefix on/off settings Custom prefixes add a user-defined string before the decoded information. For example, if you allow to add a custom prefix and set the prefix to the string "AB", after reading the barcode with the data "123", the scanner adds the string "AB"... -
Page 19: Custom Suffix On/Off Settings
User manual ‘DT3229’ 2.4.4 Custom suffix on/off settings The custom suffix adds a user-defined string after the decoded information. For example, it is allowed to add a custom suffix and set the suffix to the string "AB", after reading the barcode with the data of "123", the scanner adds the string "AB"... -
Page 20: Terminator Settings
User manual ‘DT3229’ 2.4.6 Terminator settings The terminator suffix is used to mark the end of a complete piece of data information. The terminator suffix stands alone and does not participate in any other form of data formatting. The terminator suffix must be the last piece of data sent, and no additional data will be added thereafter. -
Page 21: Case Output Settings
User manual ‘DT3229’ 2.4.7 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. Normal output (default) Convert Case Convert all to Uppercase Convert All to lowercase 2.4.8 Data output settings OPMERKING: The prefix and suffix are not processed, and the prefix and suffix are output normally. -
Page 22: Symbologies
User manual ‘DT3229’ 2.5 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. The fewer barcode types that are turned on, the faster the scanner will Scan. You can turn off the barcode types that will not be used to improve the performance of the scanner. -
Page 23: All Barcodes
User manual ‘DT3229’ 2.5.4 All barcodes Close all barcodes Turn on all barcodes 2.5.5 EAN8 Settings EAN8 on (default) EAN8 off Enable EAN8 transmission Check Character Disable EAN8 transmit Check Character (default) Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.5.6 Code 11 Settings... -
Page 24: Ean 13 Settings
User manual ‘DT3229’ 1 check bit 2 check bits Transmit check bit Not transmit check bit 2.5.7 EAN 13 settings EAN13 on (default) EAN13 off Enable EAN13 transmission Check Character Disable EAN13 transmission checks (default) Transmit EAN13 System Character (default) Do not Transmit EAN13 System Character 2.5.8 ISSN Settings... -
Page 25: Hanxin
User manual ‘DT3229’ Convert EAN-13 to ISSN Do not Convert EAN-13 to ISSN (default) 2.5.9 HANXIN Enable Disable 2.5.10 ISBN setting Set the ISBN data bits to 13 bits Set ISBN data bits to 10 bits (default) Convert EAN13 to ISBN Do not Convert EAN13 to ISBN (default) 2.5.11 UPC-A settings... -
Page 26: Upc-E Settings
User manual ‘DT3229’ Convert UPC-A to EAN13 (default) Do not Convert UPC-A to EAN13 Enable Disable Output digital Not output digital 2.5.12 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) -
Page 27: Upce
User manual ‘DT3229’ Output header Do not output header Extended to 12 bits Disable to 12 bits 2.5.13 UPCE Enable Disable 2.5.14 EAN/UPC Enable Disable 2.5.15 Code 39 Settings Code 39 on (default) Code 39 Off Datum : feb-2024 pagina 27 van 42... -
Page 28: Code 39 Length Setting
User manual ‘DT3229’ Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character Transmit Code 39 Check Character (default) Do not Transmit Code 39 start and stop Transmit Code 39 start and stop characters... -
Page 29: Code 32 Settings
User manual ‘DT3229’ 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. Scan "Save" (see Appendix 1 to save or cancel) 5. Scan "Maximum length setting"... -
Page 30: Code 93 Settings
User manual ‘DT3229’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 31: Codabar Settings
User manual ‘DT3229’ 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. Scan "Save" (see Appendix 1 to save or cancel) 5. Scan "Maximum length setting" 6. Scan Digital Code "1" "2" (see Appendix 1) 7. -
Page 32: Gs1 Databar Limited
User manual ‘DT3229’ Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" barcode 2. Scan "Minimum length setting" barcode 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 33: Composite
User manual ‘DT3229’ 2.5.27 Composite Enable Disable 2.5.28 Data matrix Code Enable Disable Enable Inverse DM Disable Inverse DM 2 of 5 enable 2 of 5 disable Matrix 2 of 5 check bit enable Matrix 2 of 5 check bit disable... -
Page 34: Msi
User manual ‘DT3229’ 2.5.29 MSI Enable Disable 2.5.30 QR Enable Disable Enable inverse QR Disable inverse QR Enable QR code URL link Disable QR code URL link 2.5.31 Micro QR code Datum : feb-2024 pagina 34 van 42 Versie : 1.0... -
Page 35: Pdf417
User manual ‘DT3229’ Enable Disable Inverse micro QR Disable inverse micro QR 2.5.32 PDF417 Enable Disable 2.5.33 Micro PDF417 Enable Disable 2.5.34 RSS-Expanded Enable Disable Datum : feb-2024 pagina 35 van 42 Versie : 1.0... -
Page 36: Rss-Limited
User manual ‘DT3229’ 2.5.35 RSS-Limited Enable Disable 2.5.36 RSS-14 Enable Disable 2.5.37 Telepen Enable Disable 2.5.38 Straight 2 of 5 Industrial Enable Disable Datum : feb-2024 pagina 36 van 42 Versie : 1.0... -
Page 37: Maxicode
User manual ‘DT3229’ 2.5.39 Maxicode Enable Disable 2.5.40 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character Do not Transmit ITF25 Check Charcter (default) 2.5.41 Aztec code... -
Page 38: Itf25 Length Setting
User manual ‘DT3229’ Enable inverse Aztec Disable inverse Aztec 2.5.42 ITF25 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 39: Appendix
User manual ‘DT3229’ 3. Appendix 3.1.1 Code ID & AIM ID Item Barcode type Code ID AIM ID Description Code 128 GS1 128 EAN-8 EAN-8 with Add-on EAN-13 EAN-13 with Add-on UPC-E UPC-E with Add-on UPC-A UPC-A with Add-on UPC-E1... - Page 40 User manual ‘DT3229’ GS1 Databar Omnidirectional GS1 Databar Limited GS1 Databar Expanded HongKong 2 of 5(China Post) Matrix 2 of 5 PDF417 m: 0,1,2 Micro PDF417 m: 0,1,2,3,4,5 Hanxin AztecCode m: 0-9,A-C QR code m: 0-6 Micro QR m: 0-6...
-
Page 41: Control Character List
User manual ‘DT3229’ 3.1.2 Control Character List Corresponding key Corresponding key value ASCII value value Hexadecimal (Ctrl key (Decimal) (Function key combination operation) operation) Null Ctrl+2 Keypad Enter Ctrl+A Caps lock Ctrl+B Right Arrow Ctrl+C Up Arrow Ctrl+D Null Ctrl+E... -
Page 42: Datum : Feb-2024 Pagina 3 Van
User manual ‘DT3229’ Ctrl+\ Ctrl+] Ctrl+6 Ctrl+- Datum : feb-2024 pagina 42 van 42 Versie : 1.0...
