- Page 1 User Manual DT3402 Barcodescanner – DT3402 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 2-2-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3402’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3402’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3402’ 2.5.13 EAN 13 settings ..................... 24 2.5.14 ISSN Settings ......................25 2.5.15 ISBN setting ......................25 2.5.16 UPC-A settings ...................... 25 2.5.17 UPC-E settings ...................... 26 2.5.18 UPCE ........................27 2.5.19 AN/UPC ......................... 27 2.5.20 Code 39 Settings ....................27 2.5.21 Code 39 Length Setting ..................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3402’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3402’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Wireless
User manual ‘DT3402’ 2.2 Wireless USB-Virtual COM Port Datum : feb-2024 pagina 8 van 44 Versie : 1.0... -
Page 9: Led
User manual ‘DT3402’ 2.2.2 Led Enable Aimer Disable Aimer Enable Illumination Disable Illumination Always off Always on Blink test mode Disable blink test mode 2.2.3 Beeper Duration Short Normal Datum : feb-2024 pagina 9 van 44 Versie : 1.0... -
Page 10: Set The Beep Switch
User manual ‘DT3402’ 2.7Khz Mute 2.2.4 Set the beep switch Open (default) Close 2.2.5 Power on beep switch Open (default) Close 2.2.6 Read success beep switch Open (default) Close Datum : feb-2024 pagina 10 van 44 Versie : 1.0... -
Page 11: Reading Mode Settings
User manual ‘DT3402’ 2.3 Reading mode settings 2.3.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. After reading the code successfully or releasing the trigger key, the code reading ends and the next decoding needs to re-enter the low level state. -
Page 12: Auto Scan Mode
User manual ‘DT3402’ Low sensitivity 2.3.4 Auto Scan mode Auto scan Delay 50ms Delay 100ms Delay 300ms 2.3.5 Code reading timeout 30sec 300sec 2400sec Datum : feb-2024 pagina 12 van 44 Versie : 1.0... -
Page 13: One Read Timeout
User manual ‘DT3402’ 2.3.6 One read timeout One time reading timeout time, the unit is 0.1 seconds. The default value is 30 (3 seconds), when set to 0, it means that the device is always in the reading state, and the time range can be set: 0~999. -
Page 14: Communication Settings
User manual ‘DT3402’ 2.4 Communication settings 2.4.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC 2.4.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Spanish (Brazil) Portuguese Portuguese (Brazil) French Datum : feb-2024 pagina 14 van 44 Versie : 1.0... -
Page 15: Usb Keyboard Sending Speed
User manual ‘DT3402’ German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America 2.4.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 16: Set Usb Keyboard Sending Speed
User manual ‘DT3402’ 20 ms 2.4.4 Set USB keyboard sending speed USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time range: 0ms~200ms. Set USB keyboard sending speed Setting the USB keyboard to send speed of 50ms can be set by reading the following barcodes in order. -
Page 17: Serial Port Baud Rate Setting
User manual ‘DT3402’ Check bit O Check bit N Check bit E 2.4.6 Serial port baud rate setting Baud rate 4800 Baud rate 9600 (default) Baud rate 19200 Baud rate 38400 Baud rate 57600 Baud rate 115200 Datum : feb-2024 pagina 17 van 44 Versie : 1.0... -
Page 18: Serial Port Parity Bit Setting
User manual ‘DT3402’ 2.4.7 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.5 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. will be added before and after the decoding information. "Custom suffix", "End suffix", etc. -
Page 19: Customized Prefixes
User manual ‘DT3402’ If set to "Off", the decoded information will only have the barcode data information, no prefix, and the default value is to turn off the custom prefix output. Clear all custom prefixes 2.5.3 Customized prefixes The custom prefix adds a user-defined string before the decoded information, and the output format after customization is "Custom Content + Barcode Content". -
Page 20: Custom Suffixes
User manual ‘DT3402’ Clear all custom suffixes Output all 2.5.5 Custom suffixes Custom suffix adds a user-defined string after the decoded information, and the output format after customization is "barcode content + custom content". Set the custom suffix to 'a' (the hex value of a is 0x61) 1. -
Page 21: Terminator Settings
User manual ‘DT3402’ Disable CODE ID (default) Code ID prefix Code ID suffix Clear all custom Code IDs 2.5.7 Terminator settings The terminator suffix is used to mark the end of a complete piece of data information. The terminator suffix stands alone and does not participate in any other form of data formatting. The terminator suffix must be the last piece of data sent, and no additional data will be added thereafter. -
Page 22: Case Output Settings
User manual ‘DT3402’ 2.5.8 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. Normal output (default) Convert Case Convert all to Uppercase Convert All to lowercase 2.5.9 All barcodes Close all barcodes Turn on all barcodes 2.5.10 EAN8 Settings... -
Page 23: Code 11 Settings
User manual ‘DT3402’ Enable EAN8 transmission Check Character Disable EAN8 transmit Check Character (default) Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.5.11 Code 11 Settings Enable Disable 1 check bit 2 check bits Transmit check bit... -
Page 24: Add-On Code Setting
User manual ‘DT3402’ 2.5.12 Add-on code setting Adaptive UPC/EAN add-on codes Only Decode UPC/EAN Add-on codes Ignore UPC/EAN add-on codes (default) 2.5.13 EAN 13 settings EAN13 on (default) EAN13 off Enable EAN13 transmission Check Character Disable EAN13 transmission checks (default) -
Page 25: Issn Settings
User manual ‘DT3402’ 2.5.14 ISSN Settings Convert EAN-13 to ISSN Do not Convert EAN-13 to ISSN (default) 2.5.15 ISBN setting Set the ISBN data bits to 13 bits Set ISBN data bits to 10 bits (default) Convert EAN13 to ISBN Do not Convert EAN13 to ISBN (default) 2.5.16 UPC-A settings... -
Page 26: Upc-E Settings
User manual ‘DT3402’ Convert UPC-A to EAN13 (default) Do not Convert UPC-A to EAN13 Enable Disable 2.5.17 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) Character Convert UPC-E to UPC-A... -
Page 27: Upce
User manual ‘DT3402’ 2.5.18 UPCE Enable Disable 2.5.19 AN/UPC Enable Disable 2.5.20 Code 39 Settings Code 39 on (default) Code 39 Off Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character... -
Page 28: Code 39 Length Setting
User manual ‘DT3402’ Do not Transmit Code 39 start and stop Transmit Code 39 start and stop characters characters (default) Full ASCII On Full ASCII Off (default) 2.5.21 Code 39 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 29: Code 32 Settings
User manual ‘DT3402’ 2.5.22 Code 32 settings Convert Code39 to Code32 Do not Convert Code39 to Code32 (default) 2.5.23 Code 128 settings Code 128 on (default) Code 128 Off 2.5.24 Code 93 settings Code 93 On (default) Code 93 Off... -
Page 30: Codabar Settings
User manual ‘DT3402’ 2.5.25 Codabar Settings Codabar on (default) Codabar Off Transmit Codabar start and stop characters Do not Transmit Codabar start and stop characters (default) 2.5.26 Codabar Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 31: Gs1 Databar Limited
User manual ‘DT3402’ 2.5.27 GS1 Databar Limited Enable Disable 2.5.28 GS1 Databar omnidirectional Enable Disable 2.5.29 Data matrix Code Enable Disable 2 of 5 enable 2 of 5 disable Datum : feb-2024 pagina 31 van 44 Versie : 1.0... -
Page 32: Msi
User manual ‘DT3402’ 2.5.30 MSI Enable Disable 2.5.31 RSS-Limited Enable Disable 2.5.32 RSS-14 Enable Disable 2.5.33 Straight 2 of 5 Industrial Enable Disable Datum : feb-2024 pagina 32 van 44 Versie : 1.0... -
Page 33: Interleave 2 Of 5 (Itf5) Setting
User manual ‘DT3402’ 2.5.34 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character Do not Transmit ITF25 Check Charcter (default) Datum : feb-2024 pagina 33 van 44... -
Page 34: Itf25 Length Setting
User manual ‘DT3402’ 2.5.35 ITF25 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 35: Appendix
User manual ‘DT3402’ 3. Appendix 3.1.1 Character Table 1001 1002 1003 SOH（01） STX（02） ETX（03） 1004 1005 1006 EOT（04） ENQ（05） ACK（06） 1007 1008 1009 BEL（07） Backspace（08） HT （09） 1010 1011 1012 LF（0A） VT（0B） FF（0C） 1013 1014 1015 CR（0D） SO（0E） SI（0F） 1016... - Page 36 User manual ‘DT3402’ 1022 1023 1024 SYN（16） ETB（17） CAN（18） 1025 1026 1027 EM（19） SUB（1A） ESC（1B） 1028 1029 1030 FS（1C） GS（1D） RS（1E） 1031 1032 1033 US（1F） Space（20） !（21） 1034 1035 1036 “（22） #（23） $（24） 1037 1038 1039 %（25） &（26） ‘（27） 1040...
- Page 37 User manual ‘DT3402’ .（2E） /（2F） 0（30） 1049 1050 1051 1073 1074 1075 1（31） 2（32） 3（33） I（49） J（4A） K（4B） 1052 1053 1054 1076 1077 1078 4（34） 5（35） 6（36） L（4C） M（4D） N（4E） 1055 1056 1057 1079 1080 1081 7（37） 8（38） 9（39） O（4F）...
- Page 38 User manual ‘DT3402’ ^（5E） _（5F） `（60） 1097 1098 1099 1121 1122 1123 a（61） b（62） c（63） y（79） z（7A） {（7B） 1100 1101 1102 1124 1125 1126 d（64） e（65） f（66） |（7C） }（7D） ~（7E） 1103 1104 1105 1127 1128 1129 g（67） h（68） i（69） Delete（7F）...
- Page 39 User manual ‘DT3402’ 1142 1143 1144 Page up Delete 1145 1146 1147 Page arrow Right arrow Left arrow 1148 1149 Down arrow Up arrow Datum : feb-2024 pagina 39 van 44 Versie : 1.0...
-
Page 40: Ascii Code Table
User manual ‘DT3402’ 3.1.2 ASCII Code table Hexadecimal ASCII value character NUL (Null char.) SOH (Start of Header) STX (Start of Text) ETX (End of Text) EOT (End of Transmission) ENQ (Enquiry) ACK (Acknowledgment) BEL (Bell) BS (Backspace) HT (Horizontal Tab) - Page 41 User manual ‘DT3402’ GS (Group Separator) RS (Request to Send) US (Unit Separator) SP (Space) ! (Exclamation Mark) " (Double Quote) # (Number Sign) $ (Dollar Sign) % (Percent) & (Ampersand) ` (Single Quote) ( (Right / Closing Parenthesis) ) (Right / Closing Parenthesis)
- Page 42 User manual ‘DT3402’ < (Less Than) = (Equal Sign) > (Greater Than) ? (Question Mark) @ (AT Symbol) Datum : feb-2024 pagina 42 van 44 Versie : 1.0...
- Page 43 User manual ‘DT3402’ [ (Left / Opening Bracket) \ (Back Slash) ] (Right / Closing Bracket) ^ (Caret / Circumflex) _ (Underscore) ' (Grave Accent) Datum : feb-2024 pagina 43 van 44 Versie : 1.0...
- Page 44 User manual ‘DT3402’ { (Left/ Opening Brace) | (Vertical Bar) } (Right/Closing Brace) ~ (Tilde) DEL (Delete) Datum : feb-2024 pagina 44 van 44 Versie : 1.0...
