- Page 1 User Manual DT3162 Barcodescanner – DT3162 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 22-1-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3162’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3162’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3162’ 2.5.6 All barcodes ......................21 2.5.7 EAN8 Settings ....................... 22 2.5.8 Code 11 Settings ....................22 2.5.9 Add-on code setting ..................... 22 2.5.10 EAN 13 settings ..................... 23 2.5.11 ISSN Settings ......................23 2.5.12 ISBN setting ......................23 2.5.13 UPC-A settings ......................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3162’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3162’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Beeper Duration
User manual ‘DT3162’ Always off Always on 2.1.5 Beeper Duration Short Normal 2.7Khz Mute 2.1.6 Beeper settings Volume set to High (50%) (default) Volume set to midrange (12,5%) 2.1.7 Set the beep switch Open (default) Close Datum : feb-2024 pagina 8 van 40... -
Page 9: Power On Beep Switch
User manual ‘DT3162’ 2.1.8 Power on beep switch Open (default) Close 2.1.9 Read success beep switch Open (default) Close 2.2 Reading mode settings 2.2.1 Level trigger mode Enter the reading state when the trigger key pin is at low level. Press and hold the trigger key to start reading code. -
Page 10: Auto Scan Mode
User manual ‘DT3162’ 2.2.3 Auto Scan mode Auto scan Delay 50ms Delay 100ms Delay 300ms 2.3 Communication settings 2.3.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC Enable virtual keyboard Disable virtual keyboard Datum : feb-2024 pagina 10 van 40 Versie : 1.0... -
Page 11: Usb Keyboard
User manual ‘DT3162’ 2.3.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Spanish (Brazil) Portuguese Portuguese (Brazil) French German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America Datum : feb-2024 pagina 11 van 40... -
Page 12: Usb Keyboard Sending Speed
User manual ‘DT3162’ 2.3.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. 5 ms (default) 10 ms 20 ms 2.3.4 Set USB keyboard sending speed... -
Page 13: Serial Communication Settings
User manual ‘DT3162’ 2.3.5 Serial communication settings Data bit 7 Data bit 8 Stop bit 1 Stop bit 2 2.3.6 Serial port baud rate setting Baud rate 4800 Baud rate 9600 (default) Baud rate 19200 Baud rate 38400 Baud rate 57600... -
Page 14: Serial Port Parity Bit Setting
User manual ‘DT3162’ 2.3.7 Serial port parity bit setting No checksum (default) Odd calibration Even Check 2.4 Data format setting Length of custom prefix and suffix: (0~10) characters, if set to "on", "Code ID prefix", "custom prefix", "end suffix", etc. will be added before and after the decoding information. "Custom suffix", "End suffix", etc. -
Page 15: Customized Prefixes
User manual ‘DT3162’ 2.4.2 Customized prefixes The custom prefix adds a user-defined string before the decoded information, and the output format after customization is "Custom Content + Barcode Content". Set the custom prefix to 'a' (the hex value of a is 0x61) 1. -
Page 16: Custom Id Output Method
User manual ‘DT3162’ Set the custom suffix to 'a' (the hex value of a is 0x61) 1. Read "Startup Settings" 2. Read the "Custom Suffix" setting code 3. Check the ASCII code of the character "a": the ASCII code of "a" is "0x61" (see ASCII code table) 4. -
Page 17: Terminator Settings
User manual ‘DT3162’ 1. Read "Startup Settings" 2. Read "Custom Code ID" 3. Check the Code ID of the barcode: the Code ID of "Codabar" is "0x61" (see the list of code system support) 4. Check the ASCII code of the character "Y": the ASCII code of "Y" is "0x59" (see ASCII code table) 5. -
Page 18: Ctrl + X
User manual ‘DT3162’ 2.4.8 CTRL + X Non- printable Keyboard Control + ASCII ( CTRL+ X) Mode ASCII control characters Windows Mode Control + X Control + X Mode Off Mode On CTRL + X Char CTRL + X function... - Page 19 User manual ‘DT3162’ CTRL+ T CTRL+ U CTRL+ V Paste CTRL+ W CTRL+ X CTRL+ Y CTRL+ Z CTRL+ [ CTRL+ \ CTRL+ ] CTRL+ ^ CTRL+ - NP Enter Datum : feb-2024 pagina 19 van 40 Versie : 1.0...
-
Page 20: Case Output Settings
User manual ‘DT3162’ 2.4.9 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. Normal output (default) Convert Case Convert all to Uppercase Convert All to lowercase 2.5 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. -
Page 21: Qr Mirror Code
User manual ‘DT3162’ 2.5.3 QR mirror code Enable Disable 2.5.4 Inverse barcode Decode regular only Decode inverse only 2.5.5 Data matrix mirror code Enable Disable 2.5.6 All barcodes Close all barcodes Turn on all barcodes Datum : feb-2024 pagina 21 van 40... -
Page 22: Ean8 Settings
User manual ‘DT3162’ 2.5.7 EAN8 Settings EAN8 on (default) EAN8 off 2.5.8 Code 11 Settings Enable Disable 1 check bit 2 check bits Transmit check bit Not transmit check bit 2.5.9 Add-on code setting Adaptive UPC/EAN add-on codes Only Decode UPC/EAN Add-on codes... -
Page 23: Ean 13 Settings
User manual ‘DT3162’ 2.5.10 EAN 13 settings EAN13 on (default) EAN13 off 2.5.11 ISSN Settings Convert EAN-13 to ISSN Do not Convert EAN-13 to ISSN (default) 2.5.12 ISBN setting Convert EAN13 to ISBN Do not Convert EAN13 to ISBN (default) 2.5.13 UPC-A settings... -
Page 24: Upc-E Settings
User manual ‘DT3162’ Enable Disable 2.5.14 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) Character Convert UPC-E to UPC-A Do not Convert UPC-E to UPC-A (default) 2.5.15 UPCE Enable Disable... -
Page 25: Ean/Upc
User manual ‘DT3162’ 2.5.16 EAN/UPC Enable Disable 2.5.17 Code 39 Settings Code 39 on (default) Code 39 Off Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character Transmit Code 39 Check Character... -
Page 26: Code 39 Length Setting
User manual ‘DT3162’ 2.5.18 Code 39 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 27: Code 128 Length Setting
User manual ‘DT3162’ 2.5.21 Code 128 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 28: Codabar Settings
User manual ‘DT3162’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 29: Gs1 Databar Limited
User manual ‘DT3162’ If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. Minimum length setting... -
Page 30: Gs1 Databar Expanded
User manual ‘DT3162’ 2.5.28 GS1 Databar Expanded Enable Disable 2.5.29 Data matrix Code Enable Disable 2 of 5 enable 2 of 5 disable Matrix 2 of 5 check bit enable Matrix 2 of 5 check bit disable Output matrix 2 of 5 check bit Not output matrix 2 of 5 check bit 2.5.30 MSI... -
Page 31: Micro Qr Code
User manual ‘DT3162’ 2.5.31 QR Enable Disable Enable QR code URL link Disable QR code URL link 2.5.32 Micro QR code Enable Disable 2.5.33 PDF417 Enable Disable 2.5.34 Micro PDF417 Enable Disable Datum : feb-2024 pagina 31 van 40 Versie : 1.0... -
Page 32: Rss-Expanded
User manual ‘DT3162’ 2.5.35 RSS-Expanded Enable Disable 2.5.36 RSS-Limited Enable Disable 2.5.37 RSS-14 Enable Disable 2.5.38 Straight 2 of 5 Industrial Enable Disable 2.5.39 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Datum : feb-2024 pagina 32 van 40... -
Page 33: Aztec Code
User manual ‘DT3162’ Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character Do not Transmit ITF25 Check Charcter (default) 2.5.40 Aztec code Enable Disable 2.5.41 ITF25 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. -
Page 34: Appendix
User manual ‘DT3162’ 3. Appendix 3.1.1 Control Character set Datum : feb-2024 pagina 34 van 40 Versie : 1.0... - Page 35 User manual ‘DT3162’ Datum : feb-2024 pagina 35 van 40 Versie : 1.0...
-
Page 36: Functional Key Mapping
User manual ‘DT3162’ 3.1.2 Functional key mapping Key（When Disable Control Key（When Enable Control Character ） Character） Save Ctrl+@ Insert Ctrl+A Home Ctrl+B Ctrl+C Delete Ctrl+D PageUp Ctrl+E PageDown Ctrl+F Ctrl+G Backspace Backspace Enter Ctrl+J Caps Lock Ctrl+K Print Screen Ctrl+L... - Page 37 User manual ‘DT3162’ ↑ Ctrl+Q ↓ Ctrl+R ← Ctrl+S → Ctrl+T Ctrl+U Ctrl+V Ctrl+W Ctrl+X Ctrl+Y Ctrl+Z Ctrl+\ Ctrl+] Ctrl+^ Ctrl+_ Datum : feb-2024 pagina 37 van 40 Versie : 1.0...
-
Page 38: Ascii Tabel
User manual ‘DT3162’ 3.1.3 ASCII Tabel <SPACE> “ & ‘ Datum : feb-2024 pagina 38 van 40 Versie : 1.0... -
Page 39: Id Set
User manual ‘DT3162’ < > 3.1.4 ID Set Symbologies CODE ID(default) All Symbologies Codabar Code128 Code32 < Code93 Code39 Code11 EAN-13 EAN-8 GS1 DataBar GS1 DataBar Limited GS1 DataBar Expanded GS1-128 (EAN-128) 2 of 5 Interleaved 2 of 5 Matrix 2 of 5... - Page 40 User manual ‘DT3162’ PDF417 Micro PDF417 QR Code Micro QR Code Datum : feb-2024 pagina 40 van 40 Versie : 1.0...
