- Page 1 User Manual DT3005 Barcodescanner – DT3005 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 23-8-2023 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3005’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3005’ INHOUDSOPGAVE Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................4 Function ..........................4 Unbox ..........................4 Start ..........................4 Window ..........................4 Reading ..........................5 Picture ..........................5 Led indicator ........................5 2. SYSTEM SETUP ........................6 System Setup ........................6 2.1.1 Setup code ...................... -
Page 4: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 5: Reading
User manual ‘DT3005’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 6: System Setup
User manual ‘DT3005’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 7: Vibration Settings
User manual ‘DT3005’ Mute 2.1.6 2.4G 1、To enter the pairing status, first scan“2.4G Receiver Mode”, then scan “Pairing Setting”(the green light will flash). 2、Plug the USB dongle into the device, when hearing a“beep”sound, it means the pairing is successful and the blue&green light is always on. (The whole pairing process takes about 1min, if timeout and the pairing failed, it will automatically exit the pairing mode);... -
Page 8: Sleep Time
User manual ‘DT3005’ Automatic 2.2.2 Sleep time The repeat read setting is only available in continuous mode. 1 min 2min 5min 30min No sleep mode Immediately sleep 2.2.3 Time display Set display front Set time back Turn off time Datum : feb-2024 pagina 8 van 28 Versie : 1.0... -
Page 9: Communication Settings
User manual ‘DT3005’ 2.3 Communication settings 1、First scan “Bluetooth HID”, then scan “Pairing Setting” to enter Bluetooth searching(Blue&green light will flash once the searching is begun); 2、Turn on Bluetooth in your device, search, select and pair “Barcode Scanner HID”, if the pairing is successful, you will hear a “beep” sound and green&flash light is always on. -
Page 10: Usb Keyboard Sending Speed
User manual ‘DT3005’ Japanese German (Switzerland) Belgium 2.3.2 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 11: Custom Prefix On/Off Settings
User manual ‘DT3005’ Upload all data Delete all data Offline Immediate mode Mixed Mode Upload in memory chip Delete all data in memory chip Show total amount scans in storage 2.3.5 Custom prefix on/off settings Custom prefixes add a user-defined string before the decoded information. For example, if you allow to add a custom prefix and set the prefix to the string "AB", after reading the barcode with... -
Page 12: Customized Prefixes
User manual ‘DT3005’ Hide the Front Character Hide the Back-end Character (prefix) (suffix) Set escape character set 0 Set escape character set 1 Set escape character set 2 Set escape character set 3 Set escape character set 4 Set GS Character Convert 2.3.6 Customized prefixes... -
Page 13: Terminator Settings
User manual ‘DT3005’ 1. Read "Startup Settings" 2. Read the "Custom Suffix" setting code 3. Check the ASCII code of the character "a": the ASCII code of "a" is "0x61" (see ASCII code table) 4. Read data code: "6" "1" (see data code table) 5. -
Page 14: Case Output Settings
User manual ‘DT3005’ 2.3.10 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. Normal output (default) Convert Case Convert all to Uppercase Convert All to lowercase Datum : feb-2024 pagina 14 van 28... -
Page 15: Appendix
User manual ‘DT3005’ 3. Appendix Chara Chara Chara Chara Chara Setting Barcode cter cter cter cter cter set 0 set 1 set 2 set 3 set4 Enter( Ctrl+ Alt+00 NULL Home pade) Ctrl+ Alt+00 Ctrl+B Lock Ctrl+ Alt+00 Right Ctrl+C... - Page 16 User manual ‘DT3005’ Ctrl+ Alt+01 Down Enter Enter Arrow Ctrl+ Alt+01 NULL NULL Ctrl+ Alt+01 NULL NULL delete Alt+01 Enter Enter Enter Enter Page Ctrl+ Alt+01 Insert Page Ctrl+ Alt+01 Down Ctrl+ Alt+01 Ctrl+ Alt+01 NULL Home Print Ctrl+ Alt+01...
- Page 17 User manual ‘DT3005’ Ctrl+ Alt+02 Ctrl+ Alt+02 Ctrl+ Alt+02 Ctrl+ Alt+02 Ctrl+ Alt+02 Ctrl+ Alt+02 NULL Alt+02 Ctrl+[ ALT+ Alt+02 Ctrl+\ ALT+ Alt+02 Ctrl+] Ctrl+ Alt+03 NULL Alt+03 NULL Ctrl+_ Datum : feb-2024 pagina 17 van 28 Versie : 1.0...
-
Page 18: Appendix 3 Control Characters Table
User manual ‘DT3005’ 3.1.1 Appendix 3 Control Characters Table Decimal ASCII Corresponding Barcode Space " & Datum : feb-2024 pagina 18 van 28 Versie : 1.0... - Page 19 User manual ‘DT3005’ Datum : feb-2024 pagina 19 van 28 Versie : 1.0...
- Page 20 User manual ‘DT3005’ < Datum : feb-2024 pagina 20 van 28 Versie : 1.0...
- Page 21 User manual ‘DT3005’ > SFF69 Datum : feb-2024 pagina 21 van 28 Versie : 1.0...
- Page 22 User manual ‘DT3005’ Datum : feb-2024 pagina 22 van 28 Versie : 1.0...
- Page 23 User manual ‘DT3005’ Datum : feb-2024 pagina 23 van 28 Versie : 1.0...
- Page 24 User manual ‘DT3005’ Datum : feb-2024 pagina 24 van 28 Versie : 1.0...
- Page 25 User manual ‘DT3005’ Datum : feb-2024 pagina 25 van 28 Versie : 1.0...
- Page 26 User manual ‘DT3005’ Datum : feb-2024 pagina 26 van 28 Versie : 1.0...
- Page 27 User manual ‘DT3005’ ¤ Ç Datum : feb-2024 pagina 27 van 28 Versie : 1.0...
-
Page 28: Appendix 4 Ascii Code Table
User manual ‘DT3005’ ç 3.1.2 Appendix 4 ASCII Code table Datum : feb-2024 pagina 28 van 28 Versie : 1.0...
