INSTALLATION MANUAL
®
BROASTER
E-Series 18
PRESSURE FRYER w/SMART TOUCH CONTROL
Be sure ALL installers read, understand, and have access to this manual at all times.
Genuine Broaster Chicken®, Broasted®, Broaster Chicken®, Broaster Foods®. and Broasterie® are registered
trademarks. Usage is available only to licensed operators with written authorization from The Broaster Company.
Broaster Company
2855 Cranston Road, Beloit, WI 53511-3991
608/365-0193 broaster.com
Design Certified By:
© 2020 Broaster Company
UL
Manual 21307 09/20 Rev 10/20
Printed In U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E Series and is the answer not in the manual?

Questions and answers

Related Manuals for Broaster E Series

Summary of Contents for Broaster E Series

  • Page 1 Be sure ALL installers read, understand, and have access to this manual at all times. Genuine Broaster Chicken®, Broasted®, Broaster Chicken®, Broaster Foods®. and Broasterie® are registered trademarks. Usage is available only to licensed operators with written authorization from The Broaster Company. Broaster Company 2855 Cranston Road, Beloit, WI 53511-3991 608/365-0193 broaster.com...
  • Page 2 Indicates a potentially hazardous situation which, if not avoided, could result in minor injury, property damage or both. All adjustments and repairs shall be made If at any time the by an authorized Broaster Company repre- touchscreen control does sentative. not turn off when the power switch is...
  • Page 3 The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). broaster.com Manual #21307 06/20 Rev: 06/20...

  • Page 4: Table Of Contents

    Example Of Piping System Design ..............4 - 7 Maximum capacity of pipe .................4 - 8 5 - OPERATIONAL CHECK-OUT ..................5 - 1 COVER ASSEMBLY ....................5 - 1 INITIAL STARTUP Electric ....................... 5 - 1 Gas ........................5 - 2 broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 5: Pre-Installation

    • Provision must be made to eliminate movement of the unit which might cause strain on electrical and gas connections. • DO NOT install unit where traffic areas are on either side or in back of unit. broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 6: Recommended Ventilation Requirements

    1800 cu. ft./minute. Canopy hood open on three sides or less: 1200 cu. ft./minute. 5. Exhaust Air Velocity: All exhaust ducts should be sized to provide an air velocity in the ducts of at least 1500 ft./ minute. broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 7: Hood Dimensions In Inches

    Hood Dimensions In Inches: broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 8: Hood Dimensions In Millimeters

    Hood Dimension In Millimeters: broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 9: Filter Pan Assembly

    2 - FILTER PAN ASSEMBLY ASSEMBLY broaster.com Manual #21307 06/20 Rev 06/20...

  • Page 10: Additional Adjustments If Needed

    20998. Install filter pan under unit and align riser line 20998 with suction line 21298. Tighten keps nuts 00552 mounting riser line 20998 to filter pan. See Operation Manual for additional assembly. broaster.com Manual #21307 06/20 Rev 06/20...

  • Page 11: Electrical Characteristics

    NFPA 70, or for Canada, the Canadian Electrical Code, CSA C22.2, as applica- ble. • Use copper wire only for connections. • If power run is over 50 feet, use next larger size wire. broaster.com Manual #17268 9/20 rev 9/20...

  • Page 12: Electrical Hookup

    Pull out and a ground wire to the GND connector. and down on bottom to remove. Check all contactor screw connections to be sure they are fully tightened for proper electrical continuity. broaster.com Manual #17268 9/20 rev 9/20...

  • Page 13: Unit Dimensions For Electrical Hook-Up

    Unit Dimensions For Electrical Hook-Up: broaster.com Manual #17268 9/20 rev 9/20...

  • Page 14: Wiring Diagram 18E

    WIRING DIAGRAM Wiring diagrams are located inside front panel. See Access For Hook-up under ELECTRICAL HOOK-UP. 18E: broaster.com Manual #17268 9/20 rev 9/20...

  • Page 15: 18G Installation

    1/2psi(3.45kPa). broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 16: Electrical Characteristics

    DO NOT cut or remove grounding prong codes, with the National Electrical Code, from this plug. ANSI/NFPA 70, or the Canadian Electri- cal Code, CSA C22.2, as applicable. broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 17: Wiring Diagrams

    18G Wiring Diagram broaster.com Manual #21307 09/20 Rev 09/20...
  • Page 18 18G Wiring Diagram Effective S/N EG8K02018Y broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 19: Gas Characteristics

    For operation at elevations above 2,000 feet above sea level, gas input must be BTU/HR Ratings: reduced 4% for each 1,000 feet. Con- US & CANADA tact your local Broaster Company repre- Natural Gas: 50,000 sentative for correct orifice sizing. Propane: 55,000 Butane: 58,000 G20: 14.65 KW net...

  • Page 20: Gas Piping

    Be sure to be used has 0.65 specific gravity and a piping will not interfere with drain pails or heating value of 1,000 BTU per cubic foot. valves. Unit Dimensions For Gas Hook-Up: broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 21: Example Of Piping System Design

    CFH = Cubic Feet/Hour C/BTU = 136,000/1,000 = 136 CFH Maximum gas demand for outlet A: C/BTU = 30,000/1,000 = 30 CFH Maximum gas demand for outlet B: C/BTU = 3,000/1,000 = 3 CFH broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 22: Maximum Capacity Of Pipe

    4,100 8,300 1,270 2,000 3,600 7,400 1,150 1,850 3,250 6,800 1,050 1,700 3,000 6,200 1,600 2,800 5,800 1,500 2,600 5,400 1,400 2,500 5,100 1,250 2,200 4,500 1,130 2,000 4,100 1,050 1,850 3,800 1,700 3,500 broaster.com Manual #21307 09/20 Rev 09/20...

  • Page 23: Operational Check-Out

    7. The next screen will require the serial number of the fryer. You can toggle between the number keys and letter keys by pressing the symbols key on the keyboard. Enter the serial number shown on the specification plate. broaster.com Manual #21307 06/20 rev 06/20...

  • Page 24: Gas

    OPEN. pan cover must be completely cleaned after each filtering cycle. 1. Clean unit as outlined in the operation manual. 2. Make sure all controls are OFF. 3. Install cover O-ring as outlined under broaster.com Manual #21307 06/20 rev 06/20...
  • Page 25 Broaster Company 2855 Cranston Road, Beloit, WI 53511-3991 608/365-0193 broaster.com...
