MicroSD card
Removing the MicroSD card
Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in
3.
Remove the air
shroud.
4.
Remove the IDSDM
module.
Steps
1. Locate the MicroSD card slot on the IDSDM module, and press the card to partially release it from the slot. For more
information on the slot location, see System board jumpers and connectors section.
2. Hold the MicroSD card and remove it from the slot..
NOTE:
Temporarily label each MicroSD card with its corresponding slot number after removal.
Figure 99. Removing the MicroSD card
Next steps
Install the MicroSD
cards.
Installing the MicroSD card
Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in
3.
Remove the air
shroud.
NOTE:
To use an MicroSD card with your system, ensure that the Internal SD Card Port is enabled in System Setup.
NOTE:
Ensure that you install the MicroSD cards into the same slots based on the labels you had marked on the cards
during removal.
98
Installing and removing system components
Safety
instructions.
Before working inside your
Safety
instructions.
Before working inside your
system.
system.
