Figure 108. Installing the IDSDM module
Next steps
1. Install the MicroSD cards.
NOTE: Reinstall the MicroSD cards into the same slots based on the labels you had marked on the cards during removal.
2. Install the air shroud.
3. Follow the procedure listed in the

Optional OCP card

Removing the OCP card

Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in
3. Remove the expansion card
Steps
1. Open the blue latch to unlock the OCP card.
2. Push the OCP card towards the rear end of the system to disconnect from the connector on the system board.
3. Slide the OCP card out of the slot on the system.
106 Installing and removing system components
After working inside your
Safety instructions.
Before working inside your
riser.
system.
system.
