Chapter 8: Configuring Filtered Services
7
In the Client Port text box, select an option from the
drop-down list. Note that you can select a range of
port numbers. The following options are available:
Ignore
Secure
Port
Client
8 In the Port field, enter the port number. If you are
entering a range, enter the lowest number of the range.
9
In the To field, enter the highest number of the range.
(If you are not entering a range, leave this field blank.)
10 Click OK.
Policy Manager adds the port configuration to the New Service
dialog box. An example of how this dialog box might look
appears in the following figure. Verify that the name, description,
and configuration of this service are correct. If necessary, click
Add to configure an additional port for this service. Repeat the
process until all ports for the service are configured.
122
Source port can be any number (0—65565). (If you
are not sure which port setting to use, choose this
option.)
Source port can range from 0—1024.
Source port must be identical to the destination
port, as listed in the Port number field of the
destination service's Properties dialog box,
Properties tab (shown below).
Source port can range from 1025—65565.
WatchGuard Firebox System
