Chapter 12 Product Specifications; Imager Product Specifications - Wasp 2D Reference Manual

Imager Product Specifications

Parameter
Dimensions (Typical):
Height
Length
Width
Weight
Aimer:
Illumination LEDs
Aiming LEDs
Skew Angle
Pitch Angle
Horizontal Velocity
Scan Contrast
Voltage Requirements
Operating Current
(Maximum)
Standby Current
(Maximum)
Product Reference Guide
Specifications
7.2 inches (18.3 cm)
4.4 inches (11.2 cm)
2.7 inches (6.9 cm)
9.6 ounces (272 g)
626nm +30nm
526nm +30nm
VGA, 640x480. Binary, TIFF, or JPEG output.
±40 degrees
±40 degrees
2 inches (5 cm) per second
45% minimum for Matrix codes, 37.5% mini-
mum for all others
4 - 14 VDC at imager
Interlaced aiming mode: 275mA@5V
Concurrent aiming mode: 450mA@5V
Normal mode: 60mA@5.5V
Low power mode: 30mA@5.5V
Chapter 12
Product
Specification
12-1
