Wasp WLP 4170 CCD

Programming Guide

Note:
The Wasp WLP 4170 CCD Scanner is ready to scan the
most popular bar codes out of the box. This manual
should only be used to make changes in the
configuration of the scanner for specific applications.
This scanner does not require software or drivers to
operate. The scanner enters data as keyboard data. Please
review this manual before scanning any of the programming
bar codes in this manual.
Tech Tip
If you are unsure of the scanner configuration or have
scanned the incorrect codes, please scan the default
bar code on page 6. This will reset the scanner to its
factory settings.
Please Read

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLP 4170 CCD and is the answer not in the manual?

Questions and answers

Related Manuals for Wasp WLP 4170 CCD

Summary of Contents for Wasp WLP 4170 CCD

  • Page 1: Programming Guide

    Programming Guide Please Read Note: The Wasp WLP 4170 CCD Scanner is ready to scan the most popular bar codes out of the box. This manual should only be used to make changes in the configuration of the scanner for specific applications.
  • Page 2 © Copyright Wasp Technologies 2002. All rights reser ved. Version 1.0 No part of this publication may be reproduced or transmitted in any form or by any means without the written permission of Wasp Technologies. The information contained in this document is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. Introduction...1 Chapter 2. Installation...2 Chapter 3. Quick Start ...3 Chapter 4. Bar Code Symbologies...4 Chapter 5. Setup & Configuration...5-34 Appendix A. Bar Code Test Symbols...30-33 Specifications ...34 Product Support, Warranty...35 ASCII Code Table ...36 1. Factory Default ...6 2.

  • Page 4: Chapter 1. Introduction

    The detectors process the measurement of every bar and space using the number of adjacent photodetectors which contrast a black mark and a white space. Wasp WLP 4170 CCD is extremely rugged since it has no moving parts. Wasp WLP 4170 CCD reader supports PC AT/XT and PS/2 keyboard interfaces and easily wedges between the computer and keyboard.

  • Page 5: Chapter 2. Installation

    2. Unplug your PC keyboard cable and plug the male end (Din 5) of the Wasp WLP 4170 CCD Scanner directly into your PC keyboard port. Plug your keyboard cable into the other end (female Din 5) of the the Wasp WLP 4170 CCD Scanner.

  • Page 6: Chapter 3. Quick Start

    Chapter 3 Quick Start Your Wasp WLP 4170 CCD Scanner is ready to go. The default settings of the Wasp WLP 4170 CCD Scanner have been pre-programmed for the most common bar code configurations. Use the "Setup & Configuration" sections only to customize the Wasp settings.

  • Page 7: Chapter 4. Bar Code Symbologies

    (greater than 0.020 in./0.50 mm). Medium and low densities are the most common since these are the easiest to read (scan) with nearly all scanning devices. Wasp WLP 4170 CCD Scanner can read bar codes with X-dimensions as low as 4 mils (0.10mm).

  • Page 8: Setup & Configuration

    Wasp WLP 4170 CCD Scanner is removed by turning off your PC. In order to configure Wasp WLP 4170 CCD Scanner, seven basic steps need to be followed for each programmed setting: (1) Determine what, if any, options on EACH PAGE that you wish to change.

  • Page 9: Factory Default

    The 'Factory Default' configuration is very useful when you need to reprogram your Wasp WLP 4170 CCD Scanner after the defaults have been changed. By setting the default configuration, the user knows precisely the configuration for each programmed setting.

  • Page 10: Beep And Delay

    Setup & Configuration —Beep and Delay The 'Beep Volume' configuration changes the volume of the audible indicator of the WLP 4170 CCD Scanner. NOTE: For help in configuring these settings, consult the programming steps on page 5. 1. Scan “Begin ”...

  • Page 11: Intercharacter Delay

    The 'Intercharacter Delay' configuration sets the speed at which the WLP 4170 CCD Scanner sends data. The intercharacter delay should be changed only if the transfer rate cannot be maintained between WLP 4170 CCD Scanner and the keyboard buffer of the computer.

  • Page 12: Keyboard Wedge

    Setup & Configuration —Keyboard Wedge The 'Keyboard Wedge' configuration supports options related to managing keyboard operations. The 'Function Code' option enables/disables support for your keyboard function keys. The 'Caps Lock' option toggles the case sensitivity of your keyboard.The ‘Laptop/No Keyboard’ setting should be enabled if you are connecting this scanner to a laptop or to a PC with no keyboard.

  • Page 13: Scanning Modes

    * Trigger with 10 Sec. Delay This is the default option for the Wasp WLP 4170 CCD Scanner. When this option is selected, the scanner will stop scanning when there is a successful read or no code is scanned after 10 seconds.

  • Page 14: Preamble/Postamble Configuration

    Setup & Configuration —Preamble and Postamble The 'Preamble' and 'Postamble' options are used to add prefix and suffix characters to the bar code value. Up to 22 characters may be added for each option separately. Note: This example illustrates how data will be fo rmatted when each option is configured. Preamble NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 15: Bar Code Symbology

    Setup & Configuration —Code 39 Code 39 is va ri a ble length and is the most frequently used symbology in industri a l bar code systems today and is ex t e n s i vely used within the Department of Defe n s e ( D O D ) .

  • Page 16: Code 39

    Setup & Configuration —Code 39 (cont.) Standard Code 39 contains only 43 characters (0-9, A-Z, $, /, %, +, -, ., SPAC E ) and can be extended to a 128 character symbology (full ASCII) by combining one of the special characters ($, /, %, +) with a letter (A-Z) to fo rm the characters that are not present in the standard Code 39 symbology.

  • Page 17: Code128

    Setup & Configuration —Code128 Code 128 is va ri a ble length and encodes the full 128 ASCII character set. Each character is represented by 11 modules that can be one of four bar widths. Code 128 is the most easily read code with the highest message integrity due to seve ral separate message check routines.
  • Page 18 Setup & Configuration —Code128 (cont.) Code 128 is the most flex i ble of all the common linear symbologies. It supports alpha and nu m e ric characters easily, has the highest number of characters per inch, and is va ri a ble length. NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 19: Upc-A

    Setup & Configuration —UPC-A UPC-A (Universal Product Code-A) is fixed length and is the most common UPC bar code for retail product labeling. It is seen in most grocery stores across the United States. The symbology encodes a 12-digit number. NOTE: For help in configuring these settings, consult the programming steps on page 5.
  • Page 20 Setup & Configuration —UPC-A (cont.) The first six digits of the UPC-A bar code are assigned from the Uniform Code Council (UCC).The next five digits are assigned by the manufacturer, and the final digit is a modulo 10 check digit.The nominal height for the UPC-A bar code is one inch.The reduced size is 80% of the nominal size.

  • Page 21: Upc-E

    Setup & Configuration —UPC-E UPC-E (Universal Product Code-E) is fixed length and is a compressed six digit code used for marking small packages, including magazines and paperback books. UPC-E symbols are UPC-A symbols that have been zero suppressed (i.e. consecutive zeros are not included in the symbol).
  • Page 22 Setup & Configuration —UPC-E (cont.) The printed value of the UPC-E code is a twelve digit code. The nominal height for the UPC- E bar code is one inch.The reduced size is 80% of the nominal size. NOTE: For help in configuring these settings, consult the programming steps on page 5.
  • Page 23 Setup & Configuration —EAN-13 The EAN/JAN-13 (European Article Number/Japanese Article Number) is fixed length and is similar to the UPC-A symbology, but encodes a 13th digit. The nominal height for the EAN/JAN-8 bar code is one inch.The reduced size is 80% of the nominal size. NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 24: Ean-13

    Setup & Configuration —EAN-13 (cont.) The EAN/JAN-13 (European Article Number/Japanese Article Number) is fixed length and is similar to the UPC-A symbology, but encodes a 13th digit. The nominal height for the EAN/JAN-8 bar code is one inch.The reduced size is 80% of the nominal size. NOTE: For help in configuring these settings, consult the programming steps on page 5.
  • Page 25 Setup & Configuration —EAN-8 The EAN/JAN-8 is fixed length and is similar to the UPC-E code, but includes two more digits for the country code. The nominal height for the EAN/JAN-8 bar code is one inch.The reduced size is 80% of the nominal size. NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 26: Ean-8

    Setup & Configuration —EAN-8 (cont.) The EAN/JAN-8 is fixed length and is similar to the UPC-E code, but includes two more digits for the country code. The nominal height for the EAN/JAN-8 bar code is one inch.The reduced size is 80% of the nominal size. NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 27: Code 93

    Setup & Configuration —Code 93 Code 93 encodes the full 128 ASCII character set using 9 modules arranged into 3 bars with adjacent spaces. Two of the characters are check chara c t e r s. Code 93 is similar to Code 39 bu t encodes more characters per inch.

  • Page 28: Interleaved 2 Of 5

    Setup & Configuration —Interleaved 2 of 5 I n t e rl e aved 2 of 5 is a va ri a ble length, even numbered, nu m e ric bar code. It is typically used in i n d u s t rial and master carton labeling and also in the automobile industry. The symbology uses bars to represent the first digit of a pair and the interl e aved (white) spaces to represent the second digit of a character pair.

  • Page 29: Codabar

    Setup & Configuration —Codabar Codabar is a variable length symbology capable of encoding six special alphanumeric characters, capital letters A through D, T, N, *, E, and all numeric digits. Codabar is one of the oldest bar code symbologies and is still used in some library applications. It should not be considered for new applications except under unusual circumstances.

  • Page 30: Codabar

    Setup & Configuration —Codabar (cont.) Codabar is a variable length symbology capable of encoding six special alphanumeric characters, capital letters A through D, T, N, *, E, and all numeric digits. Codabar is one of the oldest bar code symbologies and is still used in some library applications. It should not be considered for new applications except under unusual circumstances.

  • Page 31: Msi/Plessey

    Setup & Configuration —MSI Plessey MSI Plessey is a variable length numeric symbology and is primarily used in marking retail shelves. Each character consists of four bars with intervening spaces for each encoded digit, one or two symbol check digits, and a reverse start code. NOTE: For help in configuring these settings, consult the programming steps on page 5.

  • Page 32: Pdf417

    Setup & Configuration —PDF417 PDF417 is a 2D variable length symbology that can encode virtually any letter, number, or character. Each character consists of 4 bars and 4 spaces in a 17 module structure. The name of the symbol is derived from the format of the code. PDF stands for "Portable Data File"...

  • Page 33: Appendix A. Bar Code Test Symbols

    Setup & Configuration —Bar Code Test Symbols—Appendix A Note: Make sure that the appropriate bar code symbology is configured properly and enabled before trying to scan. Use the 'Bar Code Symbologies' configuration beginning on page 14 to enable specific symbologies. Code 39* Code 93* Interleaved 2 of 5...
  • Page 34 Setup & Configuration —Bar Code Test Symbols—Appendix A (cont.) UPC-A* UPC-A w/5 digit supplement UPC-A w/2 digit supplement UPC-E* UPC-E w/5 digit supplement UPC-E w/2 digit supplement *Default...
  • Page 35 Setup & Configuration —Bar Code Test Symbols—Appendix A (cont.) EAN/JAN 13* EAN/JAN 13 w/5 digit supplement EAN/JAN 13 w/2 digit supplement *Default...
  • Page 36 Setup & Configuration —Bar Code Test Symbols—Appendix A (cont.) EAN/JAN 8* EAN/JAN 8+5 w/5 digit supplement EAN/JAN 8 w/2 digit supplement PDF417 *Default...

  • Page 37: Specifications

    Setup & Configuration —WLP 4170 CCD Specifications MODEL OPTICAL Scanning Width Depth of Field Scan Rate ELECTRICAL Light Source Sensor Operating Voltage Current Consumption MECHANICAL Dimensions Weight Cable ENVIRONMENTAL Operating Temperature Storage Temperature Relative Humidity Safety Certification WLP 4170 3.2 in (120 mil)

  • Page 38: Product Support, Warranty

    In no event shall Wasp Bar Code be liable for consequential damages. S o m e s t a t e s, prov i n c e s, and countries do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to yo u .

  • Page 39: Ascii Code Table

    ASCII Code Table ASCII Preamble/Postamble Code Table Code ASCII Code ASCII Null Down Left Right PgUp PgDn Home Enter Insert Delete Ctrl+ Alt+ Space “ Code ASCII & ‘ < > Code ASCII Delete...
