- Page 1 V417UM0001EN ‒ 2/20/2024 User Manual V-417.E1XYHXX DRAG CHAINS M O T I O N | P O S I T I O N I N G...
-
Page 2: Table Of Contents
CONTENTS V417UM0001EN ‒ 2/20/2024 Contents Product Description..................... 3 Model Overview....................3 Product View...................... 3 Scope of Delivery....................4 Installation........................5 Specifications.......................9 Technical Data....................9 Dimensions......................9 Legal Information.......................10 M O T I O N | P O S I T I O N I N G... -
Page 3: Product Description
1 PRODUCT DESCRIPTION V417UM0001EN ‒ 2/20/2024 Product Description Model Overview Product number Description V-417.E1XYH03 Drag chain for V-412 / V-417 XY assembly, 52 mm (2'') travel range V-417.E1XYH05 Drag chain for V-412 / V-417 XY assembly, 102 mm (4'') travel range V-417.E1XYH09 Drag chain for V-412 / V-417 XY assembly, 204 mm (8'') travel... -
Page 4: Scope Of Delivery
1 PRODUCT DESCRIPTION V417UM0001EN ‒ 2/20/2024 Scope of Delivery Product number Description V-417.E1XYHxx Product according to the order (p. 3) Material for mounting the V-417.E1XYHxx drag chain: ■ 2 × socket head screw ISO 14580 M4×40 A2-050 for fixing the drag chain Chain guide(s) for Y axis of the XY system: ■... -
Page 5: Installation
2 INSTALLATION V417UM0001EN ‒ 2/20/2024 Installation Designations in these instructions: ■ X axis / lower positioner Forms the basis of a XY setup, is attached to a surface ■ Y axis / upper positioner Forms the upper axis of a XY setup, is attached to the lower positioner rotated by 90° ■... - Page 6 2 INSTALLATION V417UM0001EN ‒ 2/20/2024 b) Fix the holder for the XY drag chain with two M4×40 screws to the drag chain holder of the lower positioner. 2. Mount the Y axis on the X axis. For this purpose, use the mounting hardware of the upper positioner. a) Insert two 4h8×12 locating pins into the motion platform of the lower positioner.
- Page 7 2 INSTALLATION V417UM0001EN ‒ 2/20/2024 c) If necessary: Push the motion platform of the upper positioner to allow access to the mounting holes in its base body. d) Place flat washers on the two M6×30 screws. e) Insert the M6×30 screws with the attached flat washers into the mounting holes on the upper positioner.
- Page 8 2 INSTALLATION V417UM0001EN ‒ 2/20/2024 4. For V-417.E1XYHxx with xx = 09, 13, 17, 21, 25, 33 additionally: Mount the chain guide short on the Y axis. Use the mounting hardware of the chain guide short. a) Align the chain guide short with the mounting hole on the base body of the upper positioner that is closest to the positive end of the travel range.
-
Page 9: Specifications
3 SPECIFICATIONS V417UM0001EN ‒ 2/20/2024 Specifications Technical Data V-417.E1XYHxx Material Chain elements: igumid G/GLW Maximum velocity 2 m/s V-417.E1XYH03 V-417.E1XYH05 V-417.E1XYH09 V-417.E1XYH13 Overall mass 450 g 480 g 545 g 555 g Travel range 52 mm 102 mm 204 mm 305 mm V-417.E1XYH17 V-417.E1XYH21 V-417.E1XYH25 V-417.E1XYH33 Overall mass... -
Page 10: Legal Information
With regard thereto, Physik Instrumente (PI) GmbH & Co. KG reserves all rights. The use of any text, images and drawings is permitted only in part and only when indicating the source.
