SMC Networks IZG10-08 01 Series Quick Start Manual

One-touch fitting
Symbol Port size
08
ø8 (Metric)
09
ø5/16" (Inch)
Caution
The nozzle is specific for this product.
Do not use any other nozzle. Doing so
will adversely affect static neutralization
performance.
Accessories (for Individual Parts)
AC adapter
IZG10 CG
1
*
AC adapter
1
Symbol Type
With AC cord *
1
2
2
Without AC cord
*1 The AC adapter body and the power supply cable (For AC adapter) come as a set.
*2 The AC cord has a rated voltage of 125 V. If using an input voltage exceeding 125 VAC, select "02"
(Without AC cord) and prepare a suitable AC cord separately.
The input (AC) side and output (DC) side of the AC adapter are not isolated. If using the AC adapter as
DC power supply for a different product, this may cause an electric shock or malfunction. Do not use
the AC adapter for the DC power supply of a different product.
Nozzle assembly
IZG10 A001 01
Nozzle type
Symbol Type
01
Standard nozzle
Bypass nozzle *
02 1
*1 This nozzle is complaint with the OSHA standard for hand and portable powered tools and
equipment, general (1910.242b) requiring that "static pressure at the main orifice shall not
exceed 30 psi (210 kPa). This requirement is necessary in order to prevent a back pressure
buildup in case the nozzle is obstructed or dead ended." * Supply pressure: 0.5 MPa or less
OSHA: Occupational Safety and Health Administration
Cleaning kit
IZS30 M2
(With 1 felt pad, 1 rubber
grindstone, and 2 replacement
felt pads)
Rubber
Felt pad grindstone
185
Gun Type Ionizer
IZG10
How to Order
IZG10 08 01 01
*
AC adapter 1 , Power supply cable
Symbol Type
AC adapter (With AC cord *
01
02
AC adapter (Without AC cord)
03
Power supply cable (For 24 VDC wiring)
N
None
*1 The AC adapter body and the power supply cable (For AC adapter) come as a set. Refer to the AC adapter
image below under "Accessories."
*2 The AC cord has a rated voltage of 125 V. If using an input voltage exceeding 125 VAC, select "02" (Without
AC cord) and prepare a suitable AC cord separately.
*3 This nozzle is complaint with the OSHA standard for hand and portable powered tools and equipment, general (1910.242b)
requiring that "static pressure at the main orifice shall not exceed 30 psi (210 kPa). This requirement is necessary in order
to prevent a back pressure buildup in case the nozzle is obstructed or dead ended." * Supply pressure: 0.5 MPa or less
OSHA: Occupational Safety and Health Administration
AC adapter body
Standard nozzle
IZS30 A0201
(10 replacement
felt pads)
IZS30 A0202
(1 replacement
rubber grindstone)
Series
Nozzle type
Symbol
01
2
)
02
AC cord
Power supply cable
(For AC adapter)
Cable length: 3 m
Bypass nozzle
Removal tool
IZG10 M1
Use this tool to remove the
emitter assembly.
The removal tool is shipped
together with the product.
To order it separately, use the
product number above.
In addition, refer to the
operation manual for
replacement instructions.
RoHS
Type
Standard nozzle
Bypass nozzle *
3
Power supply cable (For 24 VDC wiring)
IZG10 CP
Cable length: 3 m
Emitter assembly
IZG10 NT
* A protective cap is attached to the tip
of the emitter when shipped.
Please remove the cap before use.
