OPERATION:
■
■ ERORR MASSAGE
STEP
BEFORE POWER ON, PLEASE CHECK THE SPECIFICATION AND
CONNECTION AGAIN.
SELF-DIAGNOSIS AND ERROR CODE:
: Display is positive-overflow (Signal is over display range)
: Display is negative-overflow (Signal is under display range)
: ADC is positive-overflow (Signal is higher than input 120%)
: ADC is negative-overflow (Signal is lower than input -120%)
/
/
/
/
/
FRONT PANEL:
■
Relay status R L 1 R L 2 R L 3 R L 4
Indication
Up screen
for Totalizer
ENT/FN
Operation Key
CS2-TM has two display screens and I/O status
indication for purposes.

Numeric Screens
Up screen: 0.28"(0.71cm) red high-brightness LED

for 10 digital totalizer.
Down screen: 0.28"(0.71cm) red high-brightness LED

for Immediate Value 4 2/3 digital or Batch 6 digital.

I/O Status Indication
Relay Energized: 4 square red LED

RL1
display when Relay 1 energized;
RL2
display when Relay 2 energized;
RL3
display when Relay 3 energized;
RL4
display when Relay 4 energized;
External Control Input Energized: 3 square green LED

ECI1
display when E.C.I. 1 close(dry contact)
ECI2
display when E.C.I. 2 close(dry contact)
ECI3
display when E.C.I. 3 close(dry contact)
RS485 Communication: 1 square red LED

will flash when the meter is receive or send data,
COM
and flash quickly means the data transient
COM
quicker.

Stickers:
Each meter has a sticker what are functions and
engineer label enclosure.
Relay energized mode:

E.C.I. functions mode:

PV.H(PV Hold) /
M.RS(Maximum or Minimum Reset) /
R.RS(Reset fo Relay Latch)
Engineer Label: over 80 types.

DESCRIPTION
: EEPROM occurs error
: Calibrating Input Signal do not process
: Calibrating Input Signal error
: Calibrating Output Signal do not process
: Calibrating Output Signal error
Control Input
status
CI11 CI2 CI3 COM
Comm. status
Down screen
for PV or Batch
L/min
Engineer Unit
H H H i L o L L D O
Tare / DI /
DISPLAY

Operating Key:
Shift(Escape) /
Setting Status
Up key
Down key
Shift the setting
Shift key
Enter/Fun
Confirmed and
key
save to EEProm

Pass Word:
Setting range:0000~9999;
User has to key in the right pass word so that get
into 【Programming Level】 . Otherwise, the meter will
go back to measuring page. If user forget the
password, please contact with the service window.

Function Lock:
None: no lock all.

User Level:
User level lock. User can get into user

level for checking but setting.
Programming Level:

User can get into programming level for
checking but setting.
ALL: All lock.
User can get into all level for

checking but setting.

Front Key Function
The Key can be set to be the same function as the

setting of ECI1.
The Key can be set to be the same function as the

setting of ECI2.
Ex. The ECI1 set to be Pv.HLd and the function
E.1=UP set to be YES in【ECI Group】. When user
presses Key, the PV will hold as like as ECI1 close.
If the front key function has been set, the terminal

input for ECI will be disabling.
6 / 27 CS2-TM(Pulse)-Operating Manual 2012-05-10
FLASH REMARK
(Please check the input
signal)
(Please check the input
signal)
(Please check the input
signal)
(Please check the input
signal)
(Please send back to
manufactory for repaired)
(Please process Calibrating
Input Signal)
(Please check Calibrating
Input Signal)
(Please process Calibrating
Output Signal)
(Please check Calibrating
Output Signal)
4 keys for Enter(Function) /
Up key / Down key
Function Index
Increase Go back to previous
number function index
Decrease Go to next
number function index
Go back to this
position function index, and
abort the setting
Setting From the function
index to get into
setting status
There are 4 levels selectable for lock.
Programming level lock.
