ADTEK CS2-TM User Manual page 10

ito.Md:
Input Time Out
Mode
AUto MAnUL
▼ ▲
The page will
show out,
when ito.Md
set to be
▼ ▲
MAnUL .
Ito: The time of
time out
rAnGE:
Input range
AUto SEMi
MAnUL
▼ ▲
AvG: Average
display for
immediate
Value(PV)
▼ ▲
d.Filt: Digital
Filter
▼ ▲
The page will
show out,
when pulse
output
▼ ▲
specified.
PLS.dv: Pulse
divider
P.CodE: Pass
code
▼ ▲
F.LoCK:
Function lock
nonE USEr
EnG ALL
▼ ▲
■ OPERATING STEPS:

USER LEVEL
POWER
ON
The page will
show out,
when rY4.Md
set to be Hi/Lo
▼ ▲
mode.
rY4.HY: Relay
4 Hysteresis
0~5000 counts
The page will
show out,
when rY4.Md
set to be Hi/Lo
▼ ▲
mode.
rY4.rd: Relay 4
energized
delay time
0:00.0~
9(M):59.9(S)
The page will
show out,
when rY4.Md
set to be Hi/Lo
▼ ▲
mode.
rY4.Fd: Relay 4
de-energized
delay time
0:00.0~
9(M):59.9(S)
DESCRIPTION
Self-diagnosis (LED All bright)
Totalizer
Batch
model number and
firmware version
PARAMETERS
Please check the specification
and wiring first.
10 / 27 CS2-TM(Pulse)-Operating Manual 2012-05-10
