ADTEK CS2-TM User Manual page 13

The page will show out, when F.tYP set
is to be PLS/F.
▼ ▲
P/F.dP: Decimal Point of Pulse/Flow or K
factor;
The page will show out, when F.tYP set
is to be PLS/F.
▼ ▲
PLS/F: Pulse/Flow(K factor);
The page will show out, when F.tYP set
is to be F/PLS.
▼ ▲
F/P.dP:Decimal Point of
Flow/Pulse(1/K factor);
The page will show out, when F.tYP set
is to be F/PLS.
▼ ▲
F/PLS: Flow/Pulse(1/K Factor);
The page will show out, when F.tYP set
is to be d.MUL.v.
▼ ▲
diA.dP: Decimal Point of Diameter for
pipe;
The page will show out, when F.tYP set
is to be d.MUL.v.
▼ ▲
diAMt: Diameter of pipe;
The page will show out, when F.tYP set
is to be d.MUL.v.
▼ ▲
vL.dP: Decimal Point of Flow Speed;
The page will show out, when F.tYP set
to be d.MUL.v.
▼ ▲
vL/HZ: Volume or Flow Rate/Hz;
Volume or Flow Rate/Hz
dP: Decimal Point of Relay Set-Point
The totalizer has been designed auto
▼ ▲
range and decimal point moving to keep
highest resolution. Therefore, user has
to set the decimal point for set-point.
ttL.dP: Decimal Point of Totalizer
Please don't set the big difference
▼ ▲
resolution between totalizer and
immediate value(PV) to cause totalizer
increasing too slowly.
UP.dSP/ttL.Md: Up screen display
selection
▼ ▲
The function is very useful to achieve batch
control. Plesae refer to the application of this
manual
oFL.Md: Run Mode after overflow for
Totalizer/Batch/Batch count;
▼ ▲
Next P.
Selectable:
0 / 0.0 / 0.00 / 0.000 / 0.0000
Up
Setting Range:
Shift
Selectable:
0 / 0.0 / 0.00 / 0.000 /
Up
Setting Range:
Shift
Selectable:
0 / 0.0 / 0.00 / 0.000 /
Up
Setting Range:
Shift
Selectable:
0 / 0.0 / 0.00 / 0.000 /
Up
Setting Range:
Shift
Selectable:
0 / 0.0 / 0.00 / 0.000 /
Up
Selectable:
0 / 0.0 / 0.00 / 0.000 /
Up
Seletable:
noMAL(Normal): Up screen
display totalizer
Bt.Cnt(Batch Counter): Up screen
display btach Counter;
Up
Selectable:
ovFL(overflow): Up screen will
show ovFL , when it is
over-flow.
rCYCL(Recycle):
re-count from 0 , when it is
over-flow.
Up
13 / 27 CS2-TM(Pulse)-Operating Manual 2015-04-24
Down Enter
0.0000~999.99
Up Down Enter
0.0000
Down Enter
0.0000~999.99
Up Down Enter
0.0000
Down Enter
0.0000~9999.9M
Up Down Enter
0.0000
Down Enter
0.0000~999.99
Up Down Enter
0.0000
Down Enter
0.0000
Down Enter
Down Enter
Up screen will
Down Enter
