ADTEK CS2-TM User Manual page 15

rAnGE(Range): Input frequency
range
▼ ▲
Adtek builds in high technology with
wide input range from 0.01Hz~
140.00KHz with auto-range function at
same unit. However, we keep three way
for the input range selection as Auto
range, Semi-Auto range and manual.
value,can only choose MAnUL
AvG: Average
The meter's sampling is 15cycle/sec. If
▼ ▲
the AvG(Average) set to be 3, it means
the meter is sampling 3 readings, and
calculating the average then update
display once. At meantime, the display
update will be 5 times/sec.
d.FiLt: Digital filter
The digital filter can reduce the magnetic
▼ ▲
noise in field.
PLS.dv: Pulse divider

▼ ▲

P.CodE: Pass Code
Please remind and write down the new
▼ ▲
pass code so that get into programming
level.
Next P.
When by the RS485 read present
PLS.dv set to be 1: It will output 1
pulse, when totalizer increases
"1Count". Ex: It will output 1 pulse,
when totalizer from 12345.678 increse
to 12345.679,
PLS.dv set to be 1000: It will output 1
pulse, when totalizer increases
"1000Count". Ex: It will output 1 pulse,
when totalizer from 12345.678 increase
to 12346.678.
Selectable:
Auto(Auto range): The decimal
point will be auto changed
according to the input
frequency so that keep
reading in the highest
resolution.
SEMi(Semi-Auto range): The
decimal point will be auto
changed according to the
input frequency to keep
reading in the highest
resolution under setting
position of decimal point.
MAnUL(Manual range): The
decimal point will be fixed
according to the setting of
decimal point. So, it's
possible to show "overflow",
if the input frequency is over
the display range.
Up
Setting Range:
1(no function)~99 times
Shift
Setting range:
0(no function)/1~99 times.
Shift
Setting Range: 1~9999
The maximum output is

1000Hz. Please sets lower
resolution of totalizer, when
the output over 1000Hz.
Duty Cycle: 50%

Please specify Relay or Open

Collect output in order
Shift
Setting Range: 0000~9999
Shift
15 / 27 CS2-TM(Pulse)-Operating Manual 2012-05-10
Down Enter
Up Down Enter
Up Down Enter
Up Down Enter
Up Down Enter
